Sub-base valve M/1700 G1/2, 5/3 centre position all ports blocked, without coil - Norgren QM/1764/6123/MD/11
Holds cylinders in any intermediate position, as the Norgren sub-base valve M/1700 QM/1764/6123/MD/11 blocks all ports in centre position and delivers 3200 l/min flow at 2.7 to 10 bar. The QM/1764/6123/MD/11 mounts on a sub-base, the solenoid coil is not included and is selected to suit the control voltage.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren sub-base valve M/1700 QM/1764/6123/MD/11 with port size G1/2 switches compressed air as a 5/3-way valve, centre position all ports blocked, at 2.7 to 10 bar. Flow of the QM/1764/6123/MD/11 is 3200 l/min, the body is made of die-cast zinc.
Benefits
- Flow 3200 l/min at an operating pressure of 2.7 to 10 bar
- Soft-seal spool made of aluminium with nitrile rubber (NBR) seals
- Centre position all ports blocked, the cylinder stays pressurised in an intermediate position
- Replacement on the sub-base without disconnecting the piping
- Temperature range 5 to 50 °C
Applications
The M/1700 series is designed for heavy duty, the QM/1764/6123/MD/11 controls cylinders in presses, woodworking machinery and steel plants with compressed air at 2.7 to 10 bar.
Standards and conformity
The QM/1764/6123/MD/11 is RoHS compliant and contains no SVHC substances under REACH.
Technical data
| Manufacturer | Norgren |
|---|---|
| Part number | QM/1764/6123/MD/11 |
| Series | M/1700 |
| Valve function | 5/3 |
| Switching mode | centre position all ports blocked |
| Actuation | solenoid pilot / solenoid pilot |
| Valve technology | soft-seal spool |
| Spool and sleeve | aluminium |
| Port size | G1/2 |
| Operating pressure | 2.7 to 10 bar |
| Flow | 3200 l/min |
| Medium | compressed air |
| Temperature range | 5 to 50 °C |
| Body material | die-cast zinc |
| Seal material | nitrile rubber (NBR) |
| Mounting | sub-base |
| Electrical connection | without solenoid coil |
| Country of origin | Germany |
| RoHS | compliant |
| REACH | no SVHC substances |
| WEEE | not subject to WEEE |
| Customs tariff number | 84812090 |
| Hersteller-Nr | QM/1764/6123/MD/11 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Ausführung | ohne Magnetspule |
| Housing material | Die-cast zinc |
| Function | 5/3 mid-position closed |
| Flow rate [l/min] | 3200 |
| Design | Piston pusher |
| Actuation type | Electrical |
| Betriebsdruck max [bar] | 10 |
| Pneumatic connection | G1/2 |
| Temperature (max.) | 50 |
