Sub-base valve M/1700 G1/2, 5/3 centre position all ports blocked, 24 V DC - Norgren M/1764/6123/MD83J

Norgren ✓ Original product Brand new

Holds cylinders in any intermediate position, as the Norgren sub-base valve M/1700 M/1764/6123/MD83J blocks all ports in centre position and delivers 3200 l/min flow at 2.7 to 10 bar. The M/1764/6123/MD83J mounts on a sub-base, its coil QM/48/83J/21 runs on 24 V DC at 6 W.

Net
€3,648.36
excl. VAT
Item NRG-M/1764/6123/MD83J
Manufacturer no. M/1764/6123/MD83J
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Norgren sub-base valve M/1700 M/1764/6123/MD83J with port size G1/2 switches compressed air as a 5/3-way valve, centre position all ports blocked, at 2.7 to 10 bar. Flow of the M/1764/6123/MD83J is 3200 l/min, the body is made of die-cast zinc.

Benefits

  • Flow 3200 l/min at an operating pressure of 2.7 to 10 bar
  • Soft-seal spool made of aluminium with nitrile rubber (NBR) seals
  • Centre position all ports blocked, the cylinder stays pressurised in an intermediate position
  • Replacement on the sub-base without disconnecting the piping
  • Coil QM/48/83J/21 with 24 V DC and 6 W
  • Temperature range 5 to 50 °C, protection class IP65 with sealed connector

Applications

The M/1700 series is designed for heavy duty, the M/1764/6123/MD83J controls cylinders in presses, woodworking machinery and steel plants with compressed air at 2.7 to 10 bar.

Standards and conformity

The M/1764/6123/MD83J is RoHS compliant and contains no SVHC substances under REACH.

Technical data

ManufacturerNorgren
Part numberM/1764/6123/MD83J
SeriesM/1700
Valve function5/3
Switching modecentre position all ports blocked
Actuationsolenoid pilot / solenoid pilot
Valve technologysoft-seal spool
Spool and sleevealuminium
Port sizeG1/2
Operating pressure2.7 to 10 bar
Flow3200 l/min
Mediumcompressed air
Temperature range5 to 50 °C
Body materialdie-cast zinc
Seal materialnitrile rubber (NBR)
Mountingsub-base
Electrical connection22 mm industrial standard
Operating voltage24 V DC
Power consumption6 W
Coil codeQM/48/83J/21
Protection classIP65 with sealed connector
Country of originGermany
RoHScompliant
REACHno SVHC substances
WEEEsubject to WEEE
Customs tariff number84812090
Hersteller-NrM/1764/6123/MD83J
Zolltarifnummer84812090
GPSR HerstellerdatenNorgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Housing materialDie-cast zinc
Function5/3 mid-position closed
Flow rate [l/min]3200
DesignPiston pusher
Actuation typeElectrical
Betriebsdruck max [bar]10
Pneumatic connectionG1/2
Protection ratingIP65
Temperature (max.)50
