In daily operation this item closes the pipeline tightly at the flange joint, and it is supplied as a backing flange DN40-PN16 (DIN). The defining values are DN 40 mm and flange connection DN40-PN16 (DIN).
Backing flange DN40-PN16 (DIN), PVC-U, 50mm, DN 40 mm, outside diameter D 153 mm
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€11.44
Item
FL-067331
Manufacturer no.
PVCLF 50
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.PVCLF 50
EAN4050571558017
Customs tariff number39174000
ConditionNew
Artikel
FL-067331
Frequently Bought Together
-
This Item:
€11.44
-
Multiple weld-on plate for 5 twin pipe clamps, size 4, twin, number of clamps 5 pcs
€27.61
-
GK-hose coupling, G 1-1/4"(female thread), brass, thread inside G 1-1/4"
€8.33
Total price
When used as a backing flange DN40-PN16 (DIN), the article closes the pipeline tightly at the flange joint. The data sheet states DN 40 mm as well as flange connection DN40-PN16 (DIN).
Benefits
- bolt pattern and sealing face to the flange standard, verified by DN 40 mm
- flange connection DN40-PN16 (DIN)
- outside diameter D 153 mm
- nominal diameter d 50 mm
- bolt circle diameter D1 110 mm
- dimensionally accurate cross section for tight joints
Technical data
| nominal diameter d [mm] | 50 |
|---|---|
| outside diameter D [mm] | 153 |
| flange connection | DN40-PN16 (DIN) |
| DN [mm] | 40 |
| bolt circle diameter D1 [mm] | 110 |
| inside diameter D2 [mm] | 62 |
| hole diameter D3 [mm] | 18 |
| number of bores | 4 |
| H [mm] | 16 |
Applications
Typical fields of application are pipework construction, vessel manufacture and process plant, rating flange connection DN40-PN16 (DIN).
| Weight | 0.230000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | PVCLF 50 |
| EAN | 4050571558017 |
| Zolltarifnummer | 39174000 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
