Backing flange DN25-PN10, similar to DIN 2642, 1.4301 pressed, DN 25 mm

Name: Backing flange DN25-PN10, similar to DIN 2642, 1.4301 pressed, DN 25 mm
Brand: Fluidics equipment
SKU: FL-022995
Price: 19.81 EUR
Availability: InStock

Fluidics equipment ✓ Original product Brand new

The a backing flange DN25-PN10 version closes the pipeline tightly at the flange joint. The data sheet states DN 25 mm as well as flange connection DN25-PN10 (DIN).

Net

€19.81

excl. VAT

Item FL-022995

Manufacturer no. FL 25 L ES

Question about this item

Datasheet (PDF)

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

Listed as a backing flange DN25-PN10, this version closes the pipeline tightly at the flange joint. Decisive here are DN 25 mm and flange connection DN25-PN10 (DIN). The version is made of 1.4301 pressed.

Benefits

bolt pattern and sealing face to the flange standard, verified by DN 25 mm
material 1.4301 pressed as stated in the data
flange connection DN25-PN10 (DIN)
D 37 mm
standard similar to DIN 2642
dimensionally accurate cross section for tight joints

Applications

Its place is in pipework construction, vessel manufacture and process plant, here with flange connection DN25-PN10 (DIN).

Technical data

material	1.4301 pressed
flange connection	DN25-PN10 (DIN)
DN [mm]	25
standard	similar to DIN 2642
number of holes	4
A [mm]	115
D [mm]	37
b [mm]	16.0
d [mm]	13.5
k [mm]	85
S [mm]	3
Weight	0.280000
Manufacturer	Fluidics equipment
Hersteller-Nr	FL 25 L ES
EAN	4050571300715
Zolltarifnummer	73072100
GPSR Herstellerdaten	A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment
Artikelzustand	New
Artikel-Authentizität	Original product
Material	1.4301 gepresst
Norm	DIN 2642
