Rodless cylinder, external guide, 32 mm, 485 mm, 483 N - Norgren M/146132/MD/485/235
The carriage runs in an external guide and the piston diameter is 32 mm. The rodless cylinder Norgren M/146132/MD/485/235 converts compressed air into a straight movement without a gearbox.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Norgren M/146132/MD/485/235 is a rodless cylinder and converts compressed air into a straight movement without a gearbox. The carriage runs in an external guide, the piston diameter is 32 mm and the stroke is 485 mm.
Benefits
- Cover strip Polyamide (PA)
- Piston seal Polyurethane (PU)
- Version with External guide
- Piston diameter 32 mm
- Stroke 485 mm
- Operating mode Double acting
Applications
It is used for pushing, lifting and clamping movements on workpieces and tools.
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren M/146132/MD/485/235 |
| Product line | Lintra Plus |
| Operating mode | Double acting |
| Guide | External guide |
| Piston diameter | 32 mm |
| Stroke | 485 mm |
| Theoretical force at 6 bar | 483 N |
| Operating pressure | 1 to 8 bar |
| Medium | Compressed air |
| Cushioning | Adjustable cushioning |
| Piston version | Magnetic |
| Cylinder barrel | Anodised aluminium |
| Cover strip | Polyamide (PA) |
| Piston seal | Polyurethane (PU) |
| Manufacturer | Norgren |
| Hersteller-Nr | M/146132/MD/485/235 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
