Lintra Plus rodless cylinder, external guide, 25 mm bore, 500 mm stroke - Norgren M/146125/M/EX/500
Delivers force and stroke to the fixture without extra mechanics. The Lintra Plus rodless cylinder Norgren M/146125/M/EX/500 works at an operating pressure of 1 to 8 bar and covers the temperature range -30 to 60 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Pneumatic cylinders create the linear movement in fixtures, feeding and assembly equipment. The Lintra Plus rodless cylinder Norgren M/146125/M/EX/500 develops a theoretical force of 294 N at 6 bar and is designed for port G1/8.
Benefits
- Light extrusion with universal mounting grooves
- Proven and patented sealing system
- Dust protection as standard
- Port size G1/8
- Operating pressure 1 to 8 bar
- Piston diameter 25 mm
Applications
Typical installations are feeding technology, handling units and fixtures in machine building.
Standards and conformity
The version is RoHS compliant, no SVHC substances are present under REACH. The product does not fall under the WEEE directive.
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren M/146125/M/EX/500 |
| Series | M/146100/M/EX |
| Product line | Lintra Plus |
| Operating mode | Double acting |
| Guiding system | External |
| Port size | G1/8 |
| Piston diameter | 25 mm |
| Stroke | 500 mm |
| Theoretical force at 6 bar | 294 N |
| Operating pressure | 1 to 8 bar |
| Medium | Compressed air |
| Temperature range | -30 to 60 °C |
| Cushioning | Adjustable cushioning |
| Piston version | Magnetic |
| Cylinder barrel | Anodised aluminium |
| Piston seal | Polyurethane (PU) |
| Cover strip | Polyamide (PA) |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | Non-WEEE |
| Manufacturer | Norgren |
| Hersteller-Nr | M/146125/M/EX/500 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
