Cutting ring fitting, thread M 10x1 (konisch), tube 8 LL (M12x1), zinc plated steel, 100 bar

The cutting ring fitting accepts the male thread M 10x1 (konisch) and a tube 8 LL (M12x1). The part clamps the cutting ring onto the tube and seals metal to metal. The operating pressure reaches up to 100 bar. The elbow design turns the line by 90 degrees and saves installation length.

Benefits

• The temperature range from -40 °C to +120 °C covers cold installation and warm machine surroundings
• Zinc plated steel carries the load of the joint in the range from -40 °C to +120 °C
• The very light series with the code LL follows the dimension series to ISO 8434-1
• The change of direction by 90 degrees saves installation length ahead of the port

Applications

Repair of existing tube fittings, test benches and power unit construction, hydraulic lines in machine and plant engineering, pipework on presses and pumps.

Standards and conformity

The tube fitting follows the design of cutting ring tube fittings to ISO 8434-1, formerly DIN 2353.
