The stud connector connects pipework to the threaded port of a device. The connection is made via the male thread M 5. The nominal pressure is stated as 16 bar.
Stud connector, male thread M 5, PN 16 bar, nickel plated brass
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€2.12
Item
FL-280507
Manufacturer no.
LE 50 MSV
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.LE 50 MSV
EAN4050571465520
Customs tariff number74122000
ConditionNew
Artikel
FL-280507
Frequently Bought Together
For stud ports on units and blocks the stud connector forms the transition. The material used is nickel plated brass. The male thread M 5 accepts the mating part. The nominal pressure is 16 bar.
Benefits
- The 60° cone provides a metal to metal seal and makes additional sealing compound unnecessary.
- 1 component connects device and line, an intermediate piece is not needed.
- Brass does not form any scale and stays free moving on the M 5 thread even after years.
- The nominal pressure of 16 bar defines the load limit of the joint.
Technical data
| Feature | Value |
|---|---|
| Material | nickel plated brass |
| Male thread | M 5 |
| Female thread | M 5 |
| PN [bar] | 16 |
Applications
Connection of pumps, valves and cylinders, control blocks, hydraulic and lubrication lines. Brass is used in device engineering, in workshops and in water installation.
| Weight | 0.009000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | LE 50 MSV |
| EAN | 4050571465520 |
| Zolltarifnummer | 74122000 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | Nickel-plated brass |
| Gewinde außen | M 5 |
| Gewinde innen | M 5 |
