Designed for supplying several consumers from one line. The joint is created via the thread 4x M 5.
Cross distributor, thread 4x M 5, length 20 mm, aluminium, for several consumers
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€8.39
Item
FL-015889
Manufacturer no.
VB 450 A
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.VB 450 A
EAN4050571718657
Customs tariff number76169990
ConditionNew
Artikel
FL-015889
Frequently Bought Together
The cross distributor keeps inlet and outlets in one bar and shortens the pipework. The connection is made via the thread 4x M 5. The overall length is 20 mm. The component is made of aluminium.
Benefits
- The 2 inlets keep the pressure at the same level over the entire bar.
- Aluminium keeps the weight of the component low and stays dimensionally stable on the 4x M 5 thread.
- The thread 4x M 5 fits the existing port without an adapter.
- At 20 mm the overall length is defined in the data sheet and can be planned in advance.
- All outlets sit in 1 bar, which shortens the pipework compared with individual branches.
Technical data
| Feature | Value |
|---|---|
| Material | aluminium |
| Version | 4-way |
| Thread | 4x M 5 |
| L [mm] | 20 |
| B [mm] | 20 |
| H [mm] | 10 |
Applications
Supply of several consumers, test benches, compressed air and hydraulic distribution on machines. Aluminium is preferably used in compressed air networks and in jig construction.
| Weight | 0.008600 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | VB 450 A |
| EAN | 4050571718657 |
| Zolltarifnummer | 76169990 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Ausführung | 4-fach |
| Material | Aluminium |
| Thread | 4x M 5 |
