In daily operation this item compensates movement and offset in the pipeline, and it is supplied as an expansion joint. The defining values are DN 32 mm and flange connection DN32-PN16 (EN).
Expansion joint, DN32-PN16 (EN), stainless steel, DN 32 mm, operating pressure -1 to 16 bar
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€388.37
Item
FL-040264
Manufacturer no.
KOMFL 32 ES
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.KOMFL 32 ES
EAN4050571444693
Customs tariff number83071000
ConditionNew
Artikel
FL-040264
Frequently Bought Together
-
This Item:
€388.37
-
Aluminium composite tube 12 x 8.2 mm, black, cut by the metre (from 75 m roll)
€10.78
-
Multi-line polyamide tubing 6 x 4 mm, 25 m roll, 7-way, hose diameter (outside x inside) 6 x 4 mm
€514.03
Total price
When used as an expansion joint, the article compensates movement and offset in the pipeline. The data sheet states DN 32 mm as well as flange connection DN32-PN16 (EN).
Benefits
- absorption of compression, extension and offset, verified by DN 32 mm
- flange connection DN32-PN16 (EN)
- operating pressure -1 to 16 bar
- version standard
- D 140 mm
- bolt pattern and sealing face to the flange standard
Technical data
| flange connection | DN32-PN16 (EN) |
|---|---|
| version | standard |
| DN [mm] | 32 |
| operating pressure [bar] | -1 to 16 |
| axial compression [mm] | 13 |
| axial extension [mm] | 13 |
| lateral offset [mm] | 0 |
| angular deflection [°] | 0 |
| L [mm] | 135 |
| D [mm] | 140 |
| number of holes | 4 |
Applications
Typical fields of application are pump connections, heating systems and process lines, rating flange connection DN32-PN16 (EN).
| Weight | 3.900000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | KOMFL 32 ES |
| EAN | 4050571444693 |
| Zolltarifnummer | 83071000 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Ausführung | Standard |
