Supplied as an expansion joint, this item compensates movement and offset in the pipeline. Decisive here are DN 25 mm and flange connection DN25-PN16 (EN).
Expansion joint, DN25-PN16 (EN), stainless steel, DN 25 mm, Standard
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€392.72
Item
FL-022630
Manufacturer no.
KOMFL 25 ES
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.KOMFL 25 ES
EAN4050571444624
Customs tariff number83071000
ConditionNew
Artikel
FL-022630
Frequently Bought Together
-
This Item:
€392.72
-
Backing flange DN125-PN10, similar to DIN 2642 and EN 1092-1 (type 02), 1.4301 pressed
€127.50
-
Air conditioning and ventilation hose, 175mm, hose diameter (inside) 175 mm
€53.14
Total price
In daily operation this item compensates movement and offset in the pipeline, and it is supplied as an expansion joint. Key figures are DN 25 mm together with flange connection DN25-PN16 (EN).
Benefits
- absorption of compression, extension and offset, verified by DN 25 mm
- flange connection DN25-PN16 (EN)
- operating pressure -1 to 16 bar
- version standard
- D 115 mm
- bolt pattern and sealing face to the flange standard
Technical data
| flange connection | DN25-PN16 (EN) |
|---|---|
| version | standard |
| DN [mm] | 25 |
| operating pressure [bar] | -1 to 16 |
| axial compression [mm] | 13 |
| axial extension [mm] | 13 |
| lateral offset [mm] | 0 |
| angular deflection [°] | 0 |
| L [mm] | 125 |
| D [mm] | 115 |
| number of holes | 4 |
Applications
It finds its place in pump connections, heating systems and process lines, in this case with flange connection DN25-PN16 (EN).
| Weight | 2.400000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | KOMFL 25 ES |
| EAN | 4050571444624 |
| Zolltarifnummer | 83071000 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Ausführung | Standard |
