Compact push-in fitting, tee design, male thread G 3/8", tube 12 mm, nickel plated brass

The compact push-in fitting accepts the male thread G 3/8" and a tube of 12 mm outside diameter. The part accepts the tube without tools and holds it by the gripping claws. The operating pressure reaches from -0.95 bar to 15 bar. The tee design sets a branch at right angles onto the main line.

Benefits

• The temperature range from -20 °C to +70 °C covers cold installation and warm machine surroundings
• Nickel plated brass as material covers the released range from -20 °C to +70 °C
• One part serves two outlets and saves additional joints
• The seal in NBR is matched to the range from -20 °C to +70 °C

Technical data

Applications

Workshop distribution and service units, compressed air installation on machines and plants, pneumatic cylinders and valve terminals, control air lines inside the control cabinet.

Standards and conformity

Only silicone free seals and lubricants are used during assembly.
