Plug socket with cable 2.5 m, angled socket KMYZ-4-24-2,5-B - Festo 193691
The Festo plug socket with cable KMYZ-4-24-2,5-B is 2.5 m long, connection: angled socket, cable, square design MSZC. Mounting On solenoid valve via M2 central screw. Current rating 1 A at 40 °C, PVC sheath. Voltage 24 V DC, range 3 to 36 V.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Festo plug socket with cable KMYZ-4-24-2,5-B is 2.5 m long, connection: angled socket, cable, square design MSZC.
Benefits
- Connection: angled socket, cable, square design MSZC
- Mounting: On solenoid valve via M2 central screw
- Electrical: 1 A at 40 °C, 24 V DC nominal voltage
- Cable sheath: PVC
- Environment: IP40, -10 to 50 °C
Applications
Typical use is driving solenoid valves with angled socket via 2.5 m of cable.
Technical data
| Type of mounting | On solenoid valve via M2 central screw |
|---|---|
| Mounting position | Any |
| Product weight | 32 g |
| Electrical connection | Angled socket, cable, square design MSZC |
| Operational voltage range DC | 3 to 36 V |
| Nominal operating voltage DC | 24 V |
| Current rating at 40 °C | 1 A |
| Protective conductor connection | Not provided |
| Cable length | 2.5 m |
| Cable characteristic | Standard |
| Cable structure | 2 x 0.35 mm² |
| Degree of protection | IP40 |
| Ambient temperature | -10 to 50 °C |
| CE mark (see declaration of conformity) | In accordance with EU RoHS Directive |
| UKCA marking (see declaration of conformity) | To UK RoHS instructions |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Note on materials | RoHS compliant |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| Material cable sheath | PVC |
| Material housing | PA |
| Material electrical contact | Bronze |
| Weight | 0.036 kg |
| Manufacturer | Festo |
| Hersteller-Nr | KMYZ-4-24-2,5-B |
| EAN | 4052568044008 |
| Zolltarifnummer | 85444290 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | PA |
| Operating voltage | 24 V DC |
| Series | KMYZ |
| Protection rating | IP40 |
| Temperaturbereich | -10-50 °C |
| Temperature (max.) | 50 |
