Plug socket with cable KMPPE-B-5 - Festo 161878
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Technical data
| Cable designation | With accessories |
|---|---|
| Frequency of connection | 500 |
| Product weight | 459 g |
| Electrical connection 1, function | Field device side |
| Electrical connection 1, design | Round |
| Electrical connection 1, connection type | Socket |
| Electrical connection 1, cable outlet | Angled |
| Electrical connection 1, connector system | M16x0.75 to EN 61076-2-106 |
| Electrical connection 1, number of connections/cores | 8 |
| Electrical connection 1, used connections/cores | 8 |
| Electrical connection 1, type of mounting | Screw-type lock |
| Electrical connection 1, connection pattern | 00995734 |
| Electrical connection 2, function | Control side |
| Electrical connection 2, connection type | Cable |
| Electrical connection 2, connector system | Open end |
| Electrical connection 2, number of connections/cores | 8 |
| Electrical connection 2, used connections/cores | 8 |
| Operational voltage range DC | 0 ... 30 V |
| Current rating at 40° C | 5 A |
| Immunity to surge | 0.6 kV |
| Shielding | Yes |
| Cable length | 5 m |
| Cable characteristic | Standard |
| Test conditions cable | Test conditions on request |
| Cable diameter | 6.8 mm |
| Cable structure | 8 x 0.25 mm² |
| Nominal cross section conductor | 0.25 mm² |
| Wire ends | Cut off bluntly |
| Degree of protection | IP67 |
| Note on degree of protection | In mounted state |
| Ambient temperature | -30 ... 80 °C |
| Ambient temperature with moving cable | -5 ... 70 °C |
| CE mark (see declaration of conformity) | In accordance with EU RoHS Directive |
| UKCA marking (see declaration of conformity) | To UK RoHS instructions |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Note on materials | RoHS compliant |
| Pollution degree | 1 |
| Material cable sheath | PVC |
| Cable sheath colour | Grey |
| Material housing | PA |
| Material screw-type lock | PA |
| Weight | 0.42 kg |
| Manufacturer | Festo |
| Hersteller-Nr | KMPPE-B-5 |
| EAN | 4052568072124 |
| Zolltarifnummer | 85444290 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
