IVAC Cleanline cylinder with valve, double acting, 50 mm bore, 80 mm stroke - Norgren PRA/882050/MIB/M4/80
The stroke can be taken straight into the fixture. Norgren PRA/882050/MIB/M4/80 has 80 mm stroke, port G1/8 and a temperature range of -2 to 70 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Norgren PRA/882050/MIB/M4/80 is a double acting IVAC Cleanline cylinder with 50 mm piston diameter and 80 mm stroke and develops a theoretical force of 1178 N.
Benefits
- Cleanline profile barrel with integrated switches
- Glandless spool valve for long service life
- Adjustable flow regulator for speed control
- Theoretical force 1178 N at 50 mm piston diameter
- Stroke 80 mm at an operating pressure of 2 to 8 bar
- Barrel made of anodised aluminium, piston rod made of martensitic stainless steel
Applications
It is built into assembly machines, packaging lines and handling units that need 80 mm of stroke and a force of 1178 N.
Standards and conformity
The version is RoHS compliant, an SVHC substance is present under REACH. The product falls under the WEEE directive. The cylinder conforms to ISO 15552. The integrated valve works in function 5/2 and is protected to IP67. The piston seal is made of Nitrile rubber (NBR).
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren PRA/882050/MIB/M4/80 |
| Series | PRA/882000/M |
| Product line | IVAC |
| Standard | ISO 15552 |
| Valve function | 5/2 |
| Actuation | Solenoid pilot / solenoid pilot |
| Operating mode | Double acting |
| Port size | G1/8 |
| Piston diameter | 50 mm |
| Stroke | 80 mm |
| Theoretical force at 6 bar | 1178 N |
| Operating pressure | 2 to 8 bar |
| Medium | Compressed air |
| Temperature range | -2 to 70 °C |
| Cushioning | Adjustable cushioning |
| Piston version | Magnetic |
| Cylinder barrel | Anodised aluminium |
| Piston rod material | Stainless steel (martensitic) |
| Piston rod thread | Male thread |
| Piston seal | Nitrile rubber (NBR) |
| Piston rod seal | Polyurethane (PU) |
| Electrical connection | M12 x 1 |
| Protection class | IP67 |
| Switch type | Solid state |
| Height | 109 mm |
| Width | 92.5 mm |
| Length | 255 mm |
| Weight | 2.156 kg |
| Country of origin | Germany |
| RoHS | Compliant |
| REACH | SVHC substance present |
| WEEE | WEEE |
| Manufacturer | Norgren |
| Hersteller-Nr | PRA/882050/MIB/M4/80 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Norm | ISO 15552 |
