IVAC Cleanline cylinder with valve, double acting, 40 mm bore, 100 mm stroke - Norgren PRA/882040/MIR/M4/100

The IVAC Cleanline cylinder Norgren PRA/882040/MIR/M4/100 works double acting at an operating pressure of 2 to 8 bar and guides the piston rod over 100 mm.

Benefits

• Cleanline profile barrel with integrated switches
• Glandless spool valve for long service life
• Adjustable flow regulator for speed control
• Theoretical force 754 N at 40 mm piston diameter
• Stroke 100 mm at an operating pressure of 2 to 8 bar
• Barrel made of anodised aluminium, piston rod made of martensitic stainless steel

Applications

Typical installations are feeding units, test benches and welding fixtures with temperatures of -2 to 70 °C.

Standards and conformity

The version is RoHS compliant, an SVHC substance is present under REACH. The product falls under the WEEE directive. The cylinder conforms to ISO 15552. The integrated valve works in function 5/2 and is protected to IP67. The piston seal is made of Nitrile rubber (NBR).
