ISOLine tie-rod single acting cylinder, 40 mm bore, 100 mm stroke - Norgren RA/801040/M/100
The piston position is sensed in the end positions without extra parts. The ISOLine tie-rod single acting cylinder Norgren RA/801040/M/100 has a piston diameter of 40 mm with 100 mm of stroke and is manufactured in Germany.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Pneumatic cylinders create the linear movement in fixtures, feeding and assembly equipment. The ISOLine tie-rod single acting cylinder Norgren RA/801040/M/100 covers the temperature range -20 to 80 °C and is manufactured in Germany.
Benefits
- Conforms to ISO 15552, VDMA 24562 and NFE 49-003-1
- High performance with stable and reliable operation
- Polyurethane seals give low friction operation and long life
- Port size G1/4
- Operating pressure 2 to 10 bar
- Piston diameter 40 mm
Applications
The cylinder handles clamping, pushing and lifting on assembly machines, packaging lines and special machinery.
Standards and conformity
The version is RoHS compliant, an SVHC substance is present under REACH. The product does not fall under the WEEE directive. The product conforms to ISO 15552.
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren RA/801040/M/100 |
| Series | RA/801000/M |
| Product line | ISOLine |
| Standard | ISO 15552 |
| Operating mode | Single acting |
| Spring position | Spring returns the rod in |
| Port size | G1/4 |
| Piston diameter | 40 mm |
| Stroke | 100 mm |
| Theoretical force at 6 bar | 648 N |
| Operating pressure | 2 to 10 bar |
| Medium | Compressed air |
| Temperature range | -20 to 80 °C |
| Cushioning | Adjustable cushioning |
| Piston version | Magnetic |
| Cylinder barrel | Anodised aluminium |
| Piston rod material | Stainless steel (martensitic) |
| Piston rod thread | Male thread |
| Piston seal | Polyurethane (PU) |
| Piston rod seal | Polyurethane (PU) |
| Height | 53 mm |
| Width | 53 mm |
| Length | 315.5 mm |
| Weight | 1.49 kg |
| Country of origin | Germany |
| RoHS | Compliant |
| REACH | SVHC substance present |
| WEEE | Non-WEEE |
| Manufacturer | Norgren |
| Hersteller-Nr | RA/801040/M/100 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Norm | ISO 15552, VDMA 24562 |
