ISOLine stainless steel tie-rod cylinder, double acting, 63 mm bore, 250 mm stroke - Norgren KA/802063/M/250

The double acting ISOLine stainless steel tie-rod cylinder Norgren KA/802063/M/250 moves a load over 250 mm of stroke and reaches a theoretical force of 1870 N at 63 mm bore.

Benefits

• Conforms to ISO 15552, VDMA 24562 and NFE 49-003-1
• High corrosion and acid resistance
• Suitable for applications in the food industry
• Theoretical force 1870 N at 63 mm piston diameter
• Stroke 250 mm at an operating pressure of 1 to 16 bar
• Barrel made of austenitic stainless steel, piston rod made of austenitic stainless steel

Applications

In the temperature range -10 to 80 °C it works in presses, switch drives and feeding units with 63 mm piston diameter.

Standards and conformity

The version is RoHS compliant, no SVHC substances are present under REACH. The product does not fall under the WEEE directive. The cylinder conforms to ISO 15552, so VDMA 24562 and NFE 49-003-1 apply as well. The piston is magnetic and can be sensed with switches. The end positions are built adaptive cushioning system acs.
