ISOLine stainless steel tie-rod cylinder ISO 15552, double-acting, 32 mm bore, 25 mm stroke, ACS cushioning, magnetic piston - Norgren KA/802032/M/25

Norgren ✓ Original product Brand new

The Norgren ISOLine stainless steel tie-rod cylinder KA/802032/M/25 offers 32 mm bore and 25 mm stroke for double-acting motion tasks on compressed air. With 482 N theoretical force and ISO 15552 dimensions the KA/802032/M/25 drops straight into the design.

Net
€621.76
excl. VAT
Item NRG-KA/802032/M/25
Manufacturer no. KA/802032/M/25
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Norgren ISOLine stainless steel tie-rod cylinder KA/802032/M/25 is a double-acting cylinder with a 32 mm bore and 25 mm of stroke.

Benefits

  • Dimensions to ISO 15552: the KA/802032/M/25 can be swapped for cylinders of the same standard and size.
  • The KA/802032/M/25 delivers a theoretical force of 482 N at 6 bar.
  • Barrel and piston rod of the KA/802032/M/25 are made of austenitic stainless steel.
  • The Adaptive Cushioning System ACS sets the end-position cushioning of the KA/802032/M/25 automatically.
  • Magnetic piston: the piston position of the KA/802032/M/25 can be sensed with cylinder switches.
  • Operating pressure 1 to 16 bar via G1/8 port on the KA/802032/M/25.

Applications

The KA/802032/M/25 suits clamping, pushing and lifting tasks where a stainless steel cylinder is required.

Technical data

ManufacturerNorgren
Order numberKA/802032/M/25
DesignISOLine stainless steel tie-rod cylinder
SeriesKA/802000/M
Product lineISOLine
StandardISO 15552, VDMA 24562
Operating modedouble-acting
Bore32 mm
Stroke25 mm
MediumCompressed air
Operating pressure1 to 16 bar
Ambient temperature-10 to 80 °C
PortG1/8
Theoretical force at 6 bar482 N
CushioningAdaptive Cushioning System ACS
Pistonmagnetic
Barrelstainless steel, austenitic
Piston rodstainless steel, austenitic
Piston rod threadmale thread
Piston sealpolyurethane (PU)
Rod sealfluoroelastomer (FPM)
Country of originGermany
RoHScompliant
Hersteller-NrKA/802032/M/25
Zolltarifnummer84123100
GPSR HerstellerdatenNorgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
BauformZugstangenzylinder
Piston Ø [mm]32
Stroke [mm]25
Seal materialFKM, PUR
Housing materialStainless steel
Functiondouble-acting
NormISO 15552, VDMA 24562
Betriebsdruck max [bar]16
Pneumatic connectionG1/8
Temperaturbereich-10-80 °C
Temperature (max.)80
