ISOLine ISO 15552 tie-rod cylinder, double-acting, 80 mm bore, 320 mm stroke, G3/8, special piston rod wiper - Norgren RA/802080/W2/320

Norgren ✓ Original product Brand new

Double-acting tie-rod cylinder with 80 mm bore and 320 mm stroke that delivers a theoretical 3016 N at 6 bar. Mounting dimensions of the RA/802080/W2/320 follow ISO 15552 and VDMA 24562, the port is G3/8.

Net
€371.38
excl. VAT
Item NRG-RA/802080/W2/320
Manufacturer no. RA/802080/W2/320
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

A theoretical 3016 N at 6 bar and 320 mm of stroke: the Norgren RA/802080/W2/320 with 80 mm bore is a double-acting tie-rod cylinder from the ISOLine range.

Benefits

  • Mounting dimensions of the RA/802080/W2/320 follow ISO 15552 and VDMA 24562.
  • The RA/802080/W2/320 has a magnetic piston for cylinder switches.
  • The RA/802080/W2/320 operates at 1 to 16 bar.
  • On the RA/802080/W2/320, the Adaptive Cushioning System (ACS) handles end-position cushioning.
  • On the RA/802080/W2/320: barrel in anodised aluminium, piston rod in martensitic stainless steel with male thread, seals in polyurethane (PU).
  • The RA/802080/W2/320 is designed for -20 to 80 °C.

Applications

Typical uses are linear drive tasks in machine and plant building, here with 320 mm of stroke.

Technical data

Product lineISOLine
SeriesRA/802000/M
StandardISO 15552, VDMA 24562
Operating modedouble-acting
Versionspecial piston rod wiper
Bore80 mm
Stroke320 mm
PortG3/8
Theoretical force at 6 bar3016 N
Operating pressure1 to 16 bar
Mediumcompressed air
Temperature range-20 to 80 °C
CushioningAdaptive Cushioning System (ACS)
Magnetic pistonyes
Barrelanodised aluminium
Piston rodstainless steel (martensitic)
Piston rod threadmale thread
Piston sealpolyurethane (PU)
Piston rod sealpolyurethane (PU)
RoHScompliant
ManufacturerNorgren
Hersteller-NrRA/802080/W2/320
Zolltarifnummer84123100
GPSR HerstellerdatenNorgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Piston Ø [mm]80
Stroke [mm]320
Seal materialPU
Housing materialAluminium, anodised
Functiondouble-acting
NormISO 15552, VDMA 24562
Betriebsdruck max [bar]16
Pneumatic connectionG3/8
Temperaturbereich-20-80 °C
Temperature (max.)80
