ISOLine tie-rod cylinder ISO 15552, double-acting, 63 mm bore, 400 mm stroke, G3/8, special piston rod wiper - Norgren RA/802063/W2/400
For pushing, lifting and clamping, the double-acting tie-rod cylinder with 63 mm bore and 400 mm stroke provides a theoretical 1870 N at 6 bar. The RA/802063/W2/400 operates from 1 to 16 bar across -20 to 80 °C and has a magnetic piston for cylinder switches. On the RA/802063/W2/400: built with special piston rod wiper.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
1870 N at 6 bar over 400 mm of stroke: that is what the Norgren RA/802063/W2/400 achieves with its 63 mm piston.
Benefits
- The RA/802063/W2/400 complies with the mounting dimensions of ISO 15552, VDMA 24562 and NFE 49-003-1.
- Polyurethane special wiper on the RA/802063/W2/400.
- Special piston rod wiper on the RA/802063/W2/400.
- Thanks to the magnetic piston the end positions at 400 mm stroke can be sensed without mechanical contact.
- The RA/802063/W2/400 works at 1 to 16 bar and -20 to 80 °C.
- ACS cushions the end positions of the RA/802063/W2/400.
Applications
Typical locations for the RA/802063/W2/400 are assembly machines, packaging machines and handling units, where 400 mm of stroke and 1870 N are needed.
Standards and compliance
The dimensions of the RA/802063/W2/400 conform to ISO 15552, so VDMA 24562 and NFE 49-003-1 apply as well. Version RA/802063/W2/400 is RoHS compliant, under REACH it contains no SVHC substances. The RA/802063/W2/400 is not subject to the WEEE directive.
Technical data
| Manufacturer | Norgren |
|---|---|
| Manufacturer part number | RA/802063/W2/400 |
| Product line | ISOLine |
| Series | RA/802000/M |
| Design | tie-rod cylinder |
| Standard | ISO 15552, VDMA 24562, NFE 49-003-1 |
| Operating mode | double-acting |
| Bore | 63 mm |
| Stroke | 400 mm |
| Version code | W2 |
| Version | special piston rod wiper |
| Port size | G3/8 |
| Theoretical force at 6 bar | 1870 N |
| Operating pressure | 1 to 16 bar |
| Medium | compressed air |
| Temperature range | -20 to 80 °C |
| Cushioning | Adaptive Cushioning System (ACS) |
| Piston | magnetic |
| Cylinder barrel | anodised aluminium |
| Piston rod material | stainless steel (martensitic) |
| Piston rod thread | male thread |
| Piston seal | polyurethane (PU) |
| Piston rod seal | polyurethane (PU) |
| Country of origin | Germany |
| RoHS | compliant |
| REACH | no SVHC substances |
| WEEE | not subject to WEEE |
| Customs tariff number | 84123100 |
| ECLASS | 51010101 |
| Hersteller-Nr | RA/802063/W2/400 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Ausführung | doppeltwirkend, Sonderabstreifer an der Kolbenstange |
| Bauform | Zugankerzylinder |
| Piston Ø [mm] | 63 |
| Stroke [mm] | 400 |
| Seal material | PU |
| Housing material | Aluminium, anodised |
| Function | double-acting |
| Norm | ISO 15552, VDMA 24562 |
| Betriebsdruck max [bar] | 16 |
| Pneumatic connection | G3/8 |
| Temperaturbereich | -20-80 °C |
| Temperature (max.) | 80 |
