ISOLine tie-rod cylinder ISO 15552, double-acting, 63 mm bore, 160 mm stroke, G3/8, special piston rod wiper - Norgren RA/802063/W2/160

Norgren ✓ Original product Brand new

1870 N theoretical force at 6 bar from a 63 mm bore and 160 mm stroke: a double-acting tie-rod cylinder for pushing, lifting and clamping. The RA/802063/W2/160 operates from 1 to 16 bar across -20 to 80 °C and has a magnetic piston for cylinder switches. Built with special piston rod wiper.

Net
€258.73
excl. VAT
Item NRG-RA/802063/W2/160
Manufacturer no. RA/802063/W2/160
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

With a 63 mm bore the Norgren RA/802063/W2/160 delivers a theoretical 1870 N at 6 bar over 160 mm of stroke.

Benefits

  • The RA/802063/W2/160 complies with the mounting dimensions of ISO 15552, VDMA 24562 and NFE 49-003-1.
  • Version with special piston rod wiper, 63 mm bore.
  • The RA/802063/W2/160 works at 1 to 16 bar and -20 to 80 °C.
  • Materials on the RA/802063/W2/160: barrel in anodised aluminium, rod in stainless steel (martensitic).
  • Special polyurethane wiper keeps dirt off the piston rod, 63 mm bore.
  • ACS cushions the end positions of the RA/802063/W2/160.

Applications

Fields of use for the RA/802063/W2/160: assembly machines, packaging machines and handling units, where 160 mm of stroke and 1870 N are needed.

Standards and compliance

The dimensions of the RA/802063/W2/160 conform to ISO 15552, so VDMA 24562 and NFE 49-003-1 apply as well. Version RA/802063/W2/160 is RoHS compliant, under REACH it contains no SVHC substances. The RA/802063/W2/160 is not subject to the WEEE directive.

Technical data

ManufacturerNorgren
Manufacturer part numberRA/802063/W2/160
Product lineISOLine
SeriesRA/802000/M
Designtie-rod cylinder
StandardISO 15552, VDMA 24562, NFE 49-003-1
Operating modedouble-acting
Bore63 mm
Stroke160 mm
Version codeW2
Versionspecial piston rod wiper
Port sizeG3/8
Theoretical force at 6 bar1870 N
Operating pressure1 to 16 bar
Mediumcompressed air
Temperature range-20 to 80 °C
CushioningAdaptive Cushioning System (ACS)
Pistonmagnetic
Cylinder barrelanodised aluminium
Piston rod materialstainless steel (martensitic)
Piston rod threadmale thread
Piston sealpolyurethane (PU)
Piston rod sealpolyurethane (PU)
Country of originGermany
RoHScompliant
REACHno SVHC substances
WEEEnot subject to WEEE
Customs tariff number84123100
ECLASS51010101
Hersteller-NrRA/802063/W2/160
Zolltarifnummer84123100
GPSR HerstellerdatenNorgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Ausführungdoppeltwirkend, Sonderabstreifer an der Kolbenstange
BauformZugankerzylinder
Piston Ø [mm]63
Stroke [mm]160
Seal materialPU
Housing materialAluminium, anodised
Functiondouble-acting
NormISO 15552, VDMA 24562
Betriebsdruck max [bar]16
Pneumatic connectionG3/8
Temperaturbereich-20-80 °C
Temperature (max.)80
