ISOLine high temperature tie-rod cylinder, double acting, 63 mm bore, 500 mm stroke - Norgren TRA/802063/M/500

The double acting ISOLine high temperature tie-rod cylinder Norgren TRA/802063/M/500 moves a load over 500 mm of stroke and reaches a theoretical force of 1870 N at 63 mm bore.

Benefits

• Conforms to ISO 15552, VDMA 24562 and NFE 49-003-1
• High stiffness and consistent behaviour over service life
• Fluoroelastomer seals allow operation up to 150 °C
• Theoretical force 1870 N at 63 mm piston diameter
• Stroke 500 mm at an operating pressure of 1 to 16 bar
• Barrel made of anodised aluminium, piston rod made of martensitic stainless steel

Applications

In the temperature range -20 to 150 °C it works in presses, switch drives and feeding units with 63 mm piston diameter.

Standards and conformity

The version is RoHS compliant, no SVHC substances are present under REACH. The product does not fall under the WEEE directive. The cylinder conforms to ISO 15552, so VDMA 24562 and NFE 49-003-1 apply as well. The piston is magnetic and can be sensed with switches. The end positions are built adaptive cushioning system acs.
