ISOLine high temperature tie-rod cylinder, double acting, 40 mm bore, 160 mm stroke - Norgren TRA/802040/M/160

The double acting ISOLine high temperature tie-rod cylinder Norgren TRA/802040/M/160 moves a load over 160 mm of stroke and reaches a theoretical force of 754 N at 40 mm bore.

Benefits

• Conforms to ISO 15552, VDMA 24562 and NFE 49-003-1
• High stiffness and consistent behaviour over service life
• Fluoroelastomer seals allow operation up to 150 °C
• Theoretical force 754 N at 40 mm piston diameter
• Stroke 160 mm at an operating pressure of 1 to 16 bar
• Barrel made of anodised aluminium, piston rod made of martensitic stainless steel

Applications

The cylinder handles clamping, pushing and lifting in fixtures, feeding technology and special machines at an operating pressure of 1 to 16 bar.

Standards and conformity

The version is RoHS compliant, no SVHC substances are present under REACH. The product does not fall under the WEEE directive. The cylinder conforms to ISO 15552, so VDMA 24562 and NFE 49-003-1 apply as well. The piston is magnetic and can be sensed with switches. The end positions are built adaptive cushioning system acs.
