ISOLine tie-rod cylinder ISO 15552, double-acting, 32 mm bore, 500 mm stroke, G1/8, up to 150 °C, magnetic piston - Norgren TRA/802032/M/500
482 N theoretical force at 6 bar from a 32 mm bore and 500 mm stroke: a double-acting tie-rod cylinder for pushing, lifting and clamping. The TRA/802032/M/500 operates from 1 to 16 bar across -20 to 150 °C and has a magnetic piston for cylinder switches. On the TRA/802032/M/500: mounting dimensions follow ISO 15552, end positions are cushioned by the Adaptive Cushioning System (ACS).
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
482 N at 6 bar over 500 mm of stroke: that is what the Norgren TRA/802032/M/500 achieves with its 32 mm piston.
Benefits
- The TRA/802032/M/500 complies with the mounting dimensions of ISO 15552, VDMA 24562 and NFE 49-003-1.
- On the TRA/802032/M/500 cylinder switches detect the magnetic piston without contact.
- ACS cushions the end positions of the TRA/802032/M/500.
- Materials on the TRA/802032/M/500: barrel in anodised aluminium, rod in stainless steel (martensitic).
- The TRA/802032/M/500 works at 1 to 16 bar and -20 to 150 °C.
Applications
Typical locations for the TRA/802032/M/500 are fixtures, feeding systems and special machines, where 500 mm of stroke and 482 N are needed.
Standards and compliance
The dimensions of the TRA/802032/M/500 conform to ISO 15552, so VDMA 24562 and NFE 49-003-1 apply as well. Version TRA/802032/M/500 is RoHS compliant, under REACH it contains no SVHC substances. The TRA/802032/M/500 is not subject to the WEEE directive.
Technical data
| Manufacturer | Norgren |
|---|---|
| Manufacturer part number | TRA/802032/M/500 |
| Product line | ISOLine |
| Series | TRA/802000/M |
| Design | tie-rod cylinder |
| Standard | ISO 15552, VDMA 24562, NFE 49-003-1 |
| Operating mode | double-acting |
| Bore | 32 mm |
| Stroke | 500 mm |
| Version code | M |
| Port size | G1/8 |
| Theoretical force at 6 bar | 482 N |
| Operating pressure | 1 to 16 bar |
| Medium | compressed air |
| Temperature range | -20 to 150 °C |
| Cushioning | Adaptive Cushioning System (ACS) |
| Piston | magnetic |
| Cylinder barrel | anodised aluminium |
| Piston rod material | stainless steel (martensitic) |
| Piston rod thread | male thread |
| Piston seal | fluoroelastomer (FKM) |
| Piston rod seal | fluoroelastomer (FKM) |
| Country of origin | Germany |
| RoHS | compliant |
| REACH | no SVHC substances |
| WEEE | not subject to WEEE |
| Customs tariff number | 84123100 |
| ECLASS | 51010101 |
| Hersteller-Nr | TRA/802032/M/500 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Ausführung | doppeltwirkend |
| Bauform | Zugankerzylinder |
| Piston Ø [mm] | 32 |
| Stroke [mm] | 500 |
| Seal material | FKM |
| Housing material | Aluminium, anodised |
| Function | double-acting |
| Norm | ISO 15552, VDMA 24562 |
| Betriebsdruck max [bar] | 16 |
| Pneumatic connection | G1/8 |
| Temperaturbereich | -20-150 °C |
| Temperature (max.) | 150 |
