ISOLine ISO 15552 tie-rod cylinder, double-acting, 125 mm bore, 125 mm stroke, G1/2, up to 150 °C, magnetic piston - Norgren TRA/802125/M/125
This double-acting tie-rod cylinder with 125 mm bore and 125 mm stroke provides a theoretical 7363 N at 6 bar. Mounting dimensions of the TRA/802125/M/125 follow ISO 15552 and VDMA 24562, the port is G1/2.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
A theoretical 7363 N at 6 bar and 125 mm of stroke: the Norgren TRA/802125/M/125 with 125 mm bore is a double-acting tie-rod cylinder from the ISOLine range.
Benefits
- Mounting dimensions of the TRA/802125/M/125 follow ISO 15552 and VDMA 24562.
- The TRA/802125/M/125 has a magnetic piston for cylinder switches.
- The TRA/802125/M/125 operates at 1 to 16 bar.
- On the TRA/802125/M/125, the Adaptive Cushioning System (ACS) handles end-position cushioning.
- Materials on the 125 mm bore version: barrel in anodised aluminium, piston rod in martensitic stainless steel with male thread, seals in fluoroelastomer (FKM).
- Rated for -20 to 150 °C with 125 mm bore and 125 mm stroke.
Applications
Typical uses are clamping, pushing and lifting in fixtures and special machines, here with 125 mm of stroke.
Technical data
| Product line | ISOLine |
|---|---|
| Series | TRA/802000/M |
| Standard | ISO 15552, VDMA 24562 |
| Operating mode | double-acting |
| Bore | 125 mm |
| Stroke | 125 mm |
| Port | G1/2 |
| Theoretical force at 6 bar | 7363 N |
| Operating pressure | 1 to 16 bar |
| Medium | compressed air |
| Temperature range | -20 to 150 °C |
| Cushioning | Adaptive Cushioning System (ACS) |
| Magnetic piston | yes |
| Barrel | anodised aluminium |
| Piston rod | stainless steel (martensitic) |
| Piston rod thread | male thread |
| Piston seal | fluoroelastomer (FKM) |
| Piston rod seal | fluoroelastomer (FKM) |
| RoHS | compliant |
| Manufacturer | Norgren |
| Hersteller-Nr | TRA/802125/M/125 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Piston Ø [mm] | 125 |
| Stroke [mm] | 125 |
| Seal material | FKM |
| Housing material | Aluminium, anodised |
| Function | double-acting |
| Norm | ISO 15552, VDMA 24562 |
| Betriebsdruck max [bar] | 16 |
| Pneumatic connection | G1/2 |
| Temperaturbereich | -20-150 °C |
| Temperature (max.) | 150 |
