ISOLine ISO 15552 tie-rod cylinder, double-acting, 80 mm bore, 125 mm stroke, G3/8, magnetic piston - Norgren RA/802080/M/125

Norgren ✓ Original product Brand new

This double-acting tie-rod cylinder with 80 mm bore and 125 mm stroke provides a theoretical 3016 N at 6 bar. Thanks to ISO 15552 and VDMA 24562 mounting dimensions it fits existing brackets, the air port is G3/8 at 125 mm stroke.

Net
€266.73
excl. VAT
Item NRG-RA/802080/M/125
Manufacturer no. RA/802080/M/125
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

A theoretical 3016 N at 6 bar and 125 mm of stroke: the Norgren RA/802080/M/125 with 80 mm bore is a double-acting tie-rod cylinder from the ISOLine range.

Benefits

  • Mounting dimensions of the RA/802080/M/125 follow ISO 15552 and VDMA 24562.
  • Magnetic piston for non-contact position sensing with cylinder switches over 125 mm of stroke.
  • Permitted pressure is 1 to 16 bar with 80 mm bore and 125 mm stroke.
  • End-position cushioning is handled by the Adaptive Cushioning System (ACS), also at 125 mm stroke.
  • On the RA/802080/M/125: barrel in anodised aluminium, piston rod in martensitic stainless steel with male thread, seals in polyurethane (PU).
  • Rated for -20 to 80 °C with 80 mm bore and 125 mm stroke.

Applications

The cylinder is used for feeding, positioning and ejecting in assembly and packaging lines, sized for 80 mm bore and 125 mm stroke.

Technical data

Product lineISOLine
SeriesRA/802000/M
StandardISO 15552, VDMA 24562
Operating modedouble-acting
Bore80 mm
Stroke125 mm
PortG3/8
Theoretical force at 6 bar3016 N
Operating pressure1 to 16 bar
Mediumcompressed air
Temperature range-20 to 80 °C
CushioningAdaptive Cushioning System (ACS)
Magnetic pistonyes
Barrelanodised aluminium
Piston rodstainless steel (martensitic)
Piston rod threadmale thread
Piston sealpolyurethane (PU)
Piston rod sealpolyurethane (PU)
Length189 mm
Width96 mm
Height96 mm
Weight2.23 kg
RoHSnot compliant
ManufacturerNorgren
Hersteller-NrRA/802080/M/125
Zolltarifnummer84123100
GPSR HerstellerdatenNorgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Piston Ø [mm]80
Stroke [mm]125
Seal materialPU
Housing materialAluminium, anodised
Functiondouble-acting
NormISO 15552, VDMA 24562
Betriebsdruck max [bar]16
Pneumatic connectionG3/8
Temperaturbereich-20-80 °C
Temperature (max.)80
