ISOLine tie-rod double acting cylinder, 63 mm bore, 500 mm stroke - Norgren RA/802063/M/EX/500
The piston position is sensed in the end positions without extra parts. The ISOLine tie-rod double acting cylinder Norgren RA/802063/M/EX/500 has a piston diameter of 63 mm with 500 mm of stroke and is designed for port G3/8.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Pneumatic cylinders create the linear movement in fixtures, feeding and assembly equipment. The ISOLine tie-rod double acting cylinder Norgren RA/802063/M/EX/500 develops a theoretical force of 1870 N at 6 bar and is suitable for compressed air.
Benefits
- Conforms to ISO 15552, VDMA 24562 and NFE 49-003-1
- High performance with stable and reliable operation
- Explosion protection according to ATEX directive 2014/34/EU
- Port size G3/8
- Operating pressure 1 to 10 bar
- Piston diameter 63 mm
Applications
Typical installations are feeding technology, handling units and fixtures in machine building.
Standards and conformity
The version is RoHS compliant, no SVHC substances are present under REACH. The product does not fall under the WEEE directive. The product conforms to ISO 15552.
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren RA/802063/M/EX/500 |
| Series | RA/802000/M/EX |
| Product line | ISOLine |
| Standard | ISO 15552 |
| Operating mode | Double acting |
| Port size | G3/8 |
| Piston diameter | 63 mm |
| Stroke | 500 mm |
| Theoretical force at 6 bar | 1870 N |
| Operating pressure | 1 to 10 bar |
| Medium | Compressed air |
| Temperature range | -20 to 60 °C |
| Cushioning | Adaptive cushioning system ACS |
| Piston version | Magnetic |
| Cylinder barrel | Anodised aluminium |
| Piston rod material | Stainless steel (martensitic) |
| Piston rod thread | Male thread |
| Piston seal | Polyurethane (PU) |
| Piston rod seal | Polyurethane (PU) |
| Country of origin | Germany |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | Non-WEEE |
| Manufacturer | Norgren |
| Hersteller-Nr | RA/802063/M/EX/500 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Norm | ISO 15552, VDMA 24562 |
| Certification | ATEX |
