ISOLine ISO 15552 tie-rod cylinder, double-acting, 63 mm bore, 160 mm stroke, G3/8, magnetic piston - Norgren RA/802063/M/160

Norgren ✓ Original product Brand new

Double-acting tie-rod cylinder with 63 mm bore and 160 mm stroke that delivers a theoretical 1870 N at 6 bar. Thanks to ISO 15552 and VDMA 24562 mounting dimensions it fits existing brackets, the air port is G3/8 at 160 mm stroke.

Net
€203.00
excl. VAT
Item NRG-RA/802063/M/160
Manufacturer no. RA/802063/M/160
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

A theoretical 1870 N at 6 bar and 160 mm of stroke: the Norgren RA/802063/M/160 with 63 mm bore is a double-acting tie-rod cylinder from the ISOLine range.

Benefits

  • Mounting dimensions of the RA/802063/M/160 follow ISO 15552 and VDMA 24562.
  • Cylinder switches pick up any position via the magnetic piston on 160 mm of stroke with a 63 mm bore.
  • Permitted pressure is 1 to 16 bar with 63 mm bore and 160 mm stroke.
  • End-position cushioning is handled by the Adaptive Cushioning System (ACS), also at 160 mm stroke.
  • On the RA/802063/M/160: barrel in anodised aluminium, piston rod in martensitic stainless steel with male thread, seals in polyurethane (PU).
  • Rated for -20 to 80 °C with 63 mm bore and 160 mm stroke.

Applications

The cylinder is used for linear drive tasks in machine and plant building, sized for 63 mm bore and 160 mm stroke.

Technical data

Product lineISOLine
SeriesRA/802000/M
StandardISO 15552, VDMA 24562
Operating modedouble-acting
Bore63 mm
Stroke160 mm
PortG3/8
Theoretical force at 6 bar1870 N
Operating pressure1 to 16 bar
Mediumcompressed air
Temperature range-20 to 80 °C
CushioningAdaptive Cushioning System (ACS)
Magnetic pistonyes
Barrelanodised aluminium
Piston rodstainless steel (martensitic)
Piston rod threadmale thread
Piston sealpolyurethane (PU)
Piston rod sealpolyurethane (PU)
Length217 mm
Width76 mm
Height76 mm
Weight1.66 kg
RoHScompliant
ManufacturerNorgren
Hersteller-NrRA/802063/M/160
Zolltarifnummer84123100
GPSR HerstellerdatenNorgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Piston Ø [mm]63
Stroke [mm]160
Seal materialPU
Housing materialAluminium, anodised
Functiondouble-acting
NormISO 15552, VDMA 24562
Betriebsdruck max [bar]16
Pneumatic connectionG3/8
Temperaturbereich-20-80 °C
Temperature (max.)80
