ISOLine ISO 15552 tie-rod cylinder, double-acting, 50 mm bore, 500 mm stroke, G1/4, magnetic piston - Norgren RA/802050/M/500

Norgren ✓ Original product Brand new

This double-acting tie-rod cylinder with 50 mm bore and 500 mm stroke provides a theoretical 1178 N at 6 bar. Thanks to ISO 15552 and VDMA 24562 mounting dimensions it fits existing brackets, the air port is G1/4 at 500 mm stroke.

Net
€206.74
excl. VAT
Item NRG-RA/802050/M/500
Manufacturer no. RA/802050/M/500
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

A theoretical 1178 N at 6 bar and 500 mm of stroke: the Norgren RA/802050/M/500 with 50 mm bore is a double-acting tie-rod cylinder from the ISOLine range.

Benefits

  • Mounting dimensions of the RA/802050/M/500 follow ISO 15552 and VDMA 24562.
  • Magnetic piston for non-contact position sensing with cylinder switches over 500 mm of stroke.
  • Permitted pressure is 1 to 16 bar with 50 mm bore and 500 mm stroke.
  • End-position cushioning is handled by the Adaptive Cushioning System (ACS), also at 500 mm stroke.
  • On the RA/802050/M/500: barrel in anodised aluminium, piston rod in martensitic stainless steel with male thread, seals in polyurethane (PU).
  • Rated for -20 to 80 °C with 50 mm bore and 500 mm stroke.

Applications

Typical uses are feeding, positioning and ejecting in assembly and packaging lines, here with 500 mm of stroke.

Technical data

Product lineISOLine
SeriesRA/802000/M
StandardISO 15552, VDMA 24562
Operating modedouble-acting
Bore50 mm
Stroke500 mm
PortG1/4
Theoretical force at 6 bar1178 N
Operating pressure1 to 16 bar
Mediumcompressed air
Temperature range-20 to 80 °C
CushioningAdaptive Cushioning System (ACS)
Magnetic pistonyes
Barrelanodised aluminium
Piston rodstainless steel (martensitic)
Piston rod threadmale thread
Piston sealpolyurethane (PU)
Piston rod sealpolyurethane (PU)
Length553 mm
Width66 mm
Height66 mm
Weight3.46 kg
RoHScompliant
ManufacturerNorgren
Hersteller-NrRA/802050/M/500
Zolltarifnummer84123100
GPSR HerstellerdatenNorgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Piston Ø [mm]50
Stroke [mm]500
Seal materialPU
Housing materialAluminium, anodised
Functiondouble-acting
NormISO 15552, VDMA 24562
Betriebsdruck max [bar]16
Pneumatic connectionG1/4
Temperaturbereich-20-80 °C
Temperature (max.)80
