ISOLine tie-rod double acting cylinder, 100 mm bore, 400 mm stroke - Norgren RA/802100/M/EX/400

Pneumatic cylinders create the linear movement in fixtures, feeding and assembly equipment. The ISOLine tie-rod double acting cylinder Norgren RA/802100/M/EX/400 works at an operating pressure of 1 to 10 bar and is designed for port G1/2.

Benefits

• Conforms to ISO 15552, VDMA 24562 and NFE 49-003-1
• High performance with stable and reliable operation
• Explosion protection according to ATEX directive 2014/34/EU
• Port size G1/2
• Operating pressure 1 to 10 bar
• Piston diameter 100 mm

Applications

The cylinder handles clamping, pushing and lifting on assembly machines, packaging lines and special machinery.

Standards and conformity

The version is RoHS compliant, no SVHC substances are present under REACH. The product does not fall under the WEEE directive. The product conforms to ISO 15552.
