The piston position is sensed in the end positions without extra parts. The ISOLine profile single acting cylinder Norgren PRA/801063/M/80 works at an operating pressure of 2 to 10 bar and weighs 2.59 kg.
ISOLine profile single acting cylinder, 63 mm bore, 80 mm stroke - Norgren PRA/801063/M/80
NORGREN
Original product
Net price (excl. VAT)
€266.72
Item
NRG-PRA/801063/M/80
Manufacturer no.
PRA/801063/M/80
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.PRA/801063/M/80
Customs tariff number84123100
ConditionNew
Artikel
NRG-PRA/801063/M/80
Frequently Bought Together
-
This Item:
€266.72
-
ISOLine tie-rod cylinder, double acting, 100 mm bore, 900 mm stroke - Norgren RA/802100/L4/900
€1,399.72
-
ISOLine profile cylinder, double acting, 40 mm bore, 300 mm stroke, G1/4 - Norgren PCA/802040/M/300
€207.25
Total price
Pneumatic cylinders create the linear movement in fixtures, feeding and assembly equipment. The ISOLine profile single acting cylinder Norgren PRA/801063/M/80 is suitable for compressed air and is designed for port G3/8.
Benefits
- Conforms to ISO 15552, VDMA 24562 and NFE 49-003-1
- High performance with stable and reliable operation
- Polyurethane seals give low friction operation and long life
- Port size G3/8
- Operating pressure 2 to 10 bar
- Piston diameter 63 mm
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren PRA/801063/M/80 |
| Series | PRA/801000/M |
| Product line | ISOLine |
| Standard | ISO 15552 |
| Operating mode | Single acting |
| Spring position | Spring returns the rod in |
| Port size | G3/8 |
| Piston diameter | 63 mm |
| Stroke | 80 mm |
| Theoretical force at 6 bar | 1735 N |
| Operating pressure | 2 to 10 bar |
| Medium | Compressed air |
| Temperature range | -20 to 80 °C |
| Cushioning | Adaptive cushioning system ACS |
| Piston version | Magnetic |
| Cylinder barrel | Anodised aluminium |
| Piston rod material | Stainless steel (martensitic) |
| Piston rod thread | Male thread |
| Piston seal | Polyurethane (PU) |
| Piston rod seal | Polyurethane (PU) |
| Height | 75 mm |
| Width | 75 mm |
| Length | 326.5 mm |
| Weight | 2.59 kg |
| Country of origin | Germany |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | Non-WEEE |
Applications
Typical installations are feeding technology, handling units and fixtures in machine building.
Standards and conformity
The version is RoHS compliant, no SVHC substances are present under REACH. The product does not fall under the WEEE directive. The product conforms to ISO 15552.
| Manufacturer | Norgren |
|---|---|
| Hersteller-Nr | PRA/801063/M/80 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Norm | ISO 15552, VDMA 24562 |
