ISOLine profile cylinder with position sensor, double acting, 100 mm bore, 500 mm stroke - Norgren PSA/802100/F1/500

Norgren PSA/802100/F1/500 is a ISOLine profile cylinder with position sensor with 100 mm bore, 500 mm stroke and an operating pressure of 1 to 12 bar.

Benefits

• Position sensor provides an absolute analogue output
• Accurate feedback of the piston position from a resistance potentiometer
• Dimensions according to ISO 15552
• Theoretical force 4710 N at 100 mm piston diameter
• Stroke 500 mm at an operating pressure of 1 to 12 bar
• Barrel made of anodised aluminium, piston rod made of austenitic stainless steel

Applications

It is used in assembly machines, packaging lines and handling units that need 500 mm of stroke and a force of 4710 N.

Standards and conformity

The version is not RoHS compliant, an SVHC substance is present under REACH. The product does not fall under the WEEE directive. The cylinder conforms to ISO 15552, so VDMA 24562 and NFE 49-003-1 apply as well. The end positions are built no cushioning.
