ISOLine profile cylinder with position sensor ISO 15552, double-acting, 100 mm bore, 250 mm stroke, G1/2 - Norgren PSA/802100/F1/250

Norgren ✓ Original product Brand new

4710 N theoretical force at 6 bar from a 100 mm bore and 250 mm stroke: a double-acting profile cylinder for pushing, lifting and clamping. The PSA/802100/F1/250 operates from 1 to 12 bar across -20 to 80 °C. On the PSA/802100/F1/250: mounting dimensions follow ISO 15552.

Net
€1,708.93
excl. VAT
Item NRG-PSA/802100/F1/250
Manufacturer no. PSA/802100/F1/250
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

4710 N at 6 bar over 250 mm of stroke: that is what the Norgren PSA/802100/F1/250 achieves with its 100 mm piston.

Benefits

  • The PSA/802100/F1/250 complies with the mounting dimensions of ISO 15552, VDMA 24562 and NFE 49-003-1.
  • Piston in non-magnetic version on the PSA/802100/F1/250.
  • The PSA/802100/F1/250 reports the piston position via a position sensor with analogue signal.
  • The PSA/802100/F1/250 works at 1 to 12 bar and -20 to 80 °C.
  • Materials on the PSA/802100/F1/250: barrel in anodised aluminium, rod in stainless steel (austenitic).

Applications

Fields of use for the PSA/802100/F1/250: fixtures, feeding systems and special machines, where 250 mm of stroke and 4710 N are needed.

Standards and compliance

The dimensions of the PSA/802100/F1/250 conform to ISO 15552, so VDMA 24562 and NFE 49-003-1 apply as well. Version PSA/802100/F1/250 is not RoHS compliant, under REACH it contains an SVHC substance. The PSA/802100/F1/250 is not subject to the WEEE directive.

Technical data

ManufacturerNorgren
Manufacturer part numberPSA/802100/F1/250
Product lineISOLine
SeriesPSA/802000/F1
Designprofile cylinder
StandardISO 15552, VDMA 24562, NFE 49-003-1
Operating modedouble-acting
Bore100 mm
Stroke250 mm
Version codeF1
Port sizeG1/2
Theoretical force at 6 bar4710 N
Operating pressure1 to 12 bar
Mediumcompressed air
Temperature range-20 to 80 °C
Cushioningno cushioning
Pistonnon-magnetic
Position measuringposition sensor, absolute analogue signal, resistance potentiometer
Cylinder barrelanodised aluminium
Piston rod materialstainless steel (austenitic)
Piston rod threadmale thread
Piston sealpolyurethane (PU)
Piston rod sealpolyurethane (PU)
Country of originGermany
RoHSnot compliant
REACHcontains an SVHC substance
WEEEnot subject to WEEE
Customs tariff number84123100
ECLASS51010101
Hersteller-NrPSA/802100/F1/250
Zolltarifnummer84123100
GPSR HerstellerdatenNorgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Ausführungdoppeltwirkend
BauformProfilzylinder
Piston Ø [mm]100
Stroke [mm]250
Seal materialPU
Housing materialAluminium, anodised
Functiondouble-acting
NormISO 15552, VDMA 24562
Betriebsdruck max [bar]12
Pneumatic connectionG1/2
Temperaturbereich-20-80 °C
Temperature (max.)80
