ISOLine ISO 15552 profile cylinder, double-acting, 80 mm bore, 25 mm stroke, G3/8, special piston rod wiper - Norgren PRA/802080/W2/25

Norgren ✓ Original product Brand new

Double-acting profile cylinder with 80 mm bore and 25 mm stroke that delivers a theoretical 3016 N at 6 bar. Mounting dimensions of the PRA/802080/W2/25 follow ISO 15552 and VDMA 24562, the port is G3/8.

Net
€296.01
excl. VAT
Item NRG-PRA/802080/W2/25
Manufacturer no. PRA/802080/W2/25
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

A theoretical 3016 N at 6 bar and 25 mm of stroke: the Norgren PRA/802080/W2/25 with 80 mm bore is a double-acting profile cylinder from the ISOLine range.

Benefits

  • Mounting dimensions of the PRA/802080/W2/25 follow ISO 15552 and VDMA 24562.
  • Cylinder switches pick up any position via the magnetic piston on 25 mm of stroke with an 80 mm bore.
  • Permitted pressure is 1 to 12 bar with 80 mm bore and 25 mm stroke.
  • On the PRA/802080/W2/25, the Adaptive Cushioning System (ACS) handles end-position cushioning.
  • On the PRA/802080/W2/25: barrel in anodised aluminium, piston rod in martensitic stainless steel with male thread, seals in polyurethane (PU).
  • Rated for -20 to 80 °C with 80 mm bore and 25 mm stroke.

Applications

The cylinder is used for clamping, pushing and lifting in fixtures and special machines, sized for 80 mm bore and 25 mm stroke.

Technical data

Product lineISOLine
SeriesPRA/802000/M
StandardISO 15552, VDMA 24562
Operating modedouble-acting
Versionspecial piston rod wiper
Bore80 mm
Stroke25 mm
PortG3/8
Theoretical force at 6 bar3016 N
Operating pressure1 to 12 bar
Mediumcompressed air
Temperature range-20 to 80 °C
CushioningAdaptive Cushioning System (ACS)
Magnetic pistonyes
Barrelanodised aluminium
Piston rodstainless steel (martensitic)
Piston rod threadmale thread
Piston sealpolyurethane (PU)
Piston rod sealpolyurethane (PU)
RoHScompliant
ManufacturerNorgren
Hersteller-NrPRA/802080/W2/25
Zolltarifnummer84123100
GPSR HerstellerdatenNorgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Piston Ø [mm]80
Stroke [mm]25
Seal materialPU
Housing materialAluminium, anodised
Functiondouble-acting
NormISO 15552, VDMA 24562
Betriebsdruck max [bar]12
Pneumatic connectionG3/8
Temperaturbereich-20-80 °C
Temperature (max.)80
