ISOLine profile cylinder ISO 15552, double-acting, 32 mm bore, 400 mm stroke, G1/8, special piston rod wiper - Norgren PRA/802032/W2/400

Norgren ✓ Original product Brand new

At 6 bar this double-acting profile cylinder with 32 mm bore and 400 mm stroke delivers a theoretical 482 N. The PRA/802032/W2/400 operates from 1 to 12 bar across -20 to 80 °C and has a magnetic piston for cylinder switches. On the PRA/802032/W2/400: mounting dimensions follow ISO 15552, end positions are cushioned by the Adaptive Cushioning System (ACS).

Net
€167.76
excl. VAT
Item NRG-PRA/802032/W2/400
Manufacturer no. PRA/802032/W2/400
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

482 N at 6 bar over 400 mm of stroke: that is what the Norgren PRA/802032/W2/400 achieves with its 32 mm piston.

Benefits

  • The PRA/802032/W2/400 complies with the mounting dimensions of ISO 15552, VDMA 24562 and NFE 49-003-1.
  • On the PRA/802032/W2/400 cylinder switches detect the magnetic piston without contact.
  • ACS cushions the end positions of the PRA/802032/W2/400.
  • Materials on the PRA/802032/W2/400: barrel in anodised aluminium, rod in stainless steel (martensitic).
  • Flush sensor mounting in the profile barrel of the PRA/802032/W2/400.
  • The PRA/802032/W2/400 works at 1 to 12 bar and -20 to 80 °C.

Applications

Typical locations for the PRA/802032/W2/400 are assembly machines, packaging machines and handling units, where 400 mm of stroke and 482 N are needed.

Standards and compliance

The dimensions of the PRA/802032/W2/400 conform to ISO 15552, so VDMA 24562 and NFE 49-003-1 apply as well. Version PRA/802032/W2/400 is RoHS compliant, under REACH it contains no SVHC substances. The PRA/802032/W2/400 is not subject to the WEEE directive.

Technical data

ManufacturerNorgren
Manufacturer part numberPRA/802032/W2/400
Product lineISOLine
SeriesPRA/802000/M
Designprofile cylinder
StandardISO 15552, VDMA 24562, NFE 49-003-1
Operating modedouble-acting
Bore32 mm
Stroke400 mm
Version codeW2
Versionspecial piston rod wiper
Port sizeG1/8
Theoretical force at 6 bar482 N
Operating pressure1 to 12 bar
Mediumcompressed air
Temperature range-20 to 80 °C
CushioningAdaptive Cushioning System (ACS)
Pistonmagnetic
Cylinder barrelanodised aluminium
Piston rod materialstainless steel (martensitic)
Piston rod threadmale thread
Piston sealpolyurethane (PU)
Piston rod sealpolyurethane (PU)
Country of originGermany
RoHScompliant
REACHno SVHC substances
WEEEnot subject to WEEE
Customs tariff number84123100
ECLASS51010101
Hersteller-NrPRA/802032/W2/400
Zolltarifnummer84123100
GPSR HerstellerdatenNorgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Ausführungdoppeltwirkend, Sonderabstreifer an der Kolbenstange
BauformProfilzylinder
Piston Ø [mm]32
Stroke [mm]400
Seal materialPU
Housing materialAluminium, anodised
Functiondouble-acting
NormISO 15552, VDMA 24562
Betriebsdruck max [bar]12
Pneumatic connectionG1/8
Temperaturbereich-20-80 °C
Temperature (max.)80
