ISOLine profile cylinder ISO 15552, double-acting, 32 mm bore, 160 mm stroke, G1/8, special piston rod wiper - Norgren PRA/802032/W2/160
482 N theoretical force at 6 bar from a 32 mm bore and 160 mm stroke: a double-acting profile cylinder for pushing, lifting and clamping. The PRA/802032/W2/160 operates from 1 to 12 bar across -20 to 80 °C and has a magnetic piston for cylinder switches. On the PRA/802032/W2/160: mounting dimensions follow ISO 15552, end positions are cushioned by the Adaptive Cushioning System (ACS).
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
482 N at 6 bar over 160 mm of stroke: that is what the Norgren PRA/802032/W2/160 achieves with its 32 mm piston.
Benefits
- The PRA/802032/W2/160 complies with the mounting dimensions of ISO 15552, VDMA 24562 and NFE 49-003-1.
- Materials on the PRA/802032/W2/160: barrel in anodised aluminium, rod in stainless steel (martensitic).
- Polyurethane special wiper on the PRA/802032/W2/160.
- Thanks to the magnetic piston the end positions at 160 mm stroke can be sensed without mechanical contact.
- ACS cushions the end positions of the PRA/802032/W2/160.
- Flush sensor mounting in the profile barrel of the PRA/802032/W2/160.
Applications
Fields of use for the PRA/802032/W2/160: fixtures, feeding systems and special machines, where 160 mm of stroke and 482 N are needed.
Standards and compliance
The dimensions of the PRA/802032/W2/160 conform to ISO 15552, so VDMA 24562 and NFE 49-003-1 apply as well. Version PRA/802032/W2/160 is RoHS compliant, under REACH it contains no SVHC substances. The PRA/802032/W2/160 is not subject to the WEEE directive.
Technical data
| Manufacturer | Norgren |
|---|---|
| Manufacturer part number | PRA/802032/W2/160 |
| Product line | ISOLine |
| Series | PRA/802000/M |
| Design | profile cylinder |
| Standard | ISO 15552, VDMA 24562, NFE 49-003-1 |
| Operating mode | double-acting |
| Bore | 32 mm |
| Stroke | 160 mm |
| Version code | W2 |
| Version | special piston rod wiper |
| Port size | G1/8 |
| Theoretical force at 6 bar | 482 N |
| Operating pressure | 1 to 12 bar |
| Medium | compressed air |
| Temperature range | -20 to 80 °C |
| Cushioning | Adaptive Cushioning System (ACS) |
| Piston | magnetic |
| Cylinder barrel | anodised aluminium |
| Piston rod material | stainless steel (martensitic) |
| Piston rod thread | male thread |
| Piston seal | polyurethane (PU) |
| Piston rod seal | polyurethane (PU) |
| Country of origin | Germany |
| RoHS | compliant |
| REACH | no SVHC substances |
| WEEE | not subject to WEEE |
| Customs tariff number | 84123100 |
| ECLASS | 51010101 |
| Hersteller-Nr | PRA/802032/W2/160 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Ausführung | doppeltwirkend, Sonderabstreifer an der Kolbenstange |
| Bauform | Profilzylinder |
| Piston Ø [mm] | 32 |
| Stroke [mm] | 160 |
| Seal material | PU |
| Housing material | Aluminium, anodised |
| Function | double-acting |
| Norm | ISO 15552, VDMA 24562 |
| Betriebsdruck max [bar] | 12 |
| Pneumatic connection | G1/8 |
| Temperaturbereich | -20-80 °C |
| Temperature (max.) | 80 |
