ISOLine profile cylinder, high temperature, double acting, 80 mm bore, 200 mm stroke - Norgren TPRA/802080/M/200

Norgren TPRA/802080/M/200 is a double acting ISOLine profile cylinder with 80 mm piston diameter and 200 mm stroke and develops a theoretical force of 3016 N.

Benefits

• Conforms to ISO 15552, VDMA 24562 and NFE 49-003-1
• High stiffness and consistent behaviour over service life
• Fluoroelastomer seals allow operation up to 150 °C
• Theoretical force 3016 N at 80 mm piston diameter
• Stroke 200 mm at an operating pressure of 1 to 12 bar
• Barrel made of anodised aluminium, piston rod made of martensitic stainless steel

Applications

It is built into assembly machines, packaging lines and handling units that need 200 mm of stroke and a force of 3016 N.

Standards and conformity

The version is RoHS compliant, no SVHC substances are present under REACH. The product does not fall under the WEEE directive. The cylinder conforms to ISO 15552. VDMA 24562 and NFE 49-003-1 therefore apply as well. The fluoroelastomer seals allow operation up to 150 °C. The piston seal is made of Fluoroelastomer (FKM).
