ISOLine profile cylinder, high temperature, double acting, 63 mm bore, 500 mm stroke - Norgren TPRA/802063/M/500
Handles clamping, pushing and lifting without additional hydraulics. Norgren TPRA/802063/M/500 develops a theoretical force of 1870 N at 63 mm piston diameter and 500 mm stroke.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The ISOLine profile cylinder Norgren TPRA/802063/M/500 works double acting at an operating pressure of 1 to 12 bar and guides the piston rod over 500 mm.
Benefits
- Conforms to ISO 15552, VDMA 24562 and NFE 49-003-1
- High stiffness and consistent behaviour over service life
- Fluoroelastomer seals allow operation up to 150 °C
- Theoretical force 1870 N at 63 mm piston diameter
- Stroke 500 mm at an operating pressure of 1 to 12 bar
- Barrel made of anodised aluminium, piston rod made of martensitic stainless steel
Applications
The cylinder handles clamping, pushing and lifting in fixtures, feeding technology and special machinery at an operating pressure of 1 to 12 bar.
Standards and conformity
The version is RoHS compliant, no SVHC substances are present under REACH. The product does not fall under the WEEE directive. The cylinder conforms to ISO 15552. VDMA 24562 and NFE 49-003-1 therefore apply as well. The fluoroelastomer seals allow operation up to 150 °C. The piston seal is made of Fluoroelastomer (FKM).
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren TPRA/802063/M/500 |
| Series | TPRA/802000/M |
| Product line | ISOLine |
| Standard | ISO 15552 |
| Operating mode | Double acting |
| Port size | G3/8 |
| Piston diameter | 63 mm |
| Stroke | 500 mm |
| Theoretical force at 6 bar | 1870 N |
| Operating pressure | 1 to 12 bar |
| Medium | Compressed air |
| Temperature range | -20 to 150 °C |
| Cushioning | Adaptive cushioning system ACS |
| Piston version | Magnetic |
| Cylinder barrel | Anodised aluminium |
| Piston rod material | Stainless steel (martensitic) |
| Piston rod thread | Male thread |
| Piston seal | Fluoroelastomer (FKM) |
| Piston rod seal | Fluoroelastomer (FKM) |
| Country of origin | Germany |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | Non-WEEE |
| Manufacturer | Norgren |
| Hersteller-Nr | TPRA/802063/M/500 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Norm | ISO 15552, VDMA 24562 |
