ISOLine profile cylinder, high temperature, double acting, 50 mm bore, 125 mm stroke - Norgren TPRA/802050/M/125

Norgren TPRA/802050/M/125 is a double acting ISOLine profile cylinder with 50 mm piston diameter and 125 mm stroke and develops a theoretical force of 1178 N.

Benefits

• Conforms to ISO 15552, VDMA 24562 and NFE 49-003-1
• High stiffness and consistent behaviour over service life
• Fluoroelastomer seals allow operation up to 150 °C
• Theoretical force 1178 N at 50 mm piston diameter
• Stroke 125 mm at an operating pressure of 1 to 12 bar
• Barrel made of anodised aluminium, piston rod made of martensitic stainless steel

Technical data

Applications

It is built into assembly machines, packaging lines and handling units that need 125 mm of stroke and a force of 1178 N.

Standards and conformity

The version is RoHS compliant, no SVHC substances are present under REACH. The product does not fall under the WEEE directive. The cylinder conforms to ISO 15552. VDMA 24562 and NFE 49-003-1 therefore apply as well. The fluoroelastomer seals allow operation up to 150 °C. The piston seal is made of Fluoroelastomer (FKM).
