ISOLine profile cylinder, double acting, 100 mm bore, 320 mm stroke - Norgren PRA/802100/M/320

The double acting ISOLine profile cylinder Norgren PRA/802100/M/320 has a piston diameter of 100 mm with 320 mm stroke and reaches a theoretical force of 4710 N.

Benefits

• Conforms to ISO 15552, VDMA 24562 and NFE 49-003-1
• High stiffness and consistent behaviour over service life
• Polyurethane seals for low friction operation and long life
• Switches mount flush with the profile barrel
• Theoretical force 4710 N at 100 mm piston diameter
• Stroke 320 mm at an operating pressure of 1 to 12 bar
• Barrel made of anodised aluminium, piston rod made of martensitic stainless steel
• Temperature range -20 to 80 °C, cushioning adaptive cushioning system acs

Applications

The cylinder handles clamping, pushing and lifting in fixtures, feeding technology and special machines at an operating pressure of 1 to 12 bar.

Standards and conformity

The version is not RoHS compliant, an SVHC substance is present under REACH. The product does not fall under the WEEE directive. The cylinder conforms to ISO 15552. VDMA 24562 and NFE 49-003-1 therefore apply as well. The piston seal is made of Polyurethane (PU).
