ISO Star solenoid valve 5/3 centre open to exhaust, ISO 3, 110/120 V AC, 4650 l/min - Norgren SXE9775-A50-00-18J
With 4650 l/min flow in size ISO 3, the Norgren SXE9775-A50-00-18J covers the 5/3 centre open to exhaust function across 2 to 10 bar. The SXE9775-A50-00-18J is driven with 110/120 V AC at 4/2.5 VA via a 22 mm industrial standard connection.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Norgren SXE9775-A50-00-18J is a ISO Star solenoid valve for 5/3 centre open to exhaust in size ISO 3, rated for 2 to 10 bar and 4650 l/min flow. The QM/48/18J/21 coil of the SXE9775-A50-00-18J runs on 110/120 V AC at 4/2.5 VA, protection class IP65 with sealed plug. A glandless spool and sleeve in hard anodised aluminium with PTFE coating gives the SXE9775-A50-00-18J lubrication-free operation and long service life.
Benefits
- Glandless spool and sleeve, b10 value 24,000,000 cycles
- Flow 4650 l/min at 2 to 10 bar operating pressure
- Coil QM/48/18J/21 for 110/120 V AC, 4/2.5 VA
- Electrical connection 22 mm industrial standard, protection class IP65 with sealed plug
- Interface to ISO 5599-1, size ISO 3
- Temperature range -15 to 50 °C
Applications
The SXE9775-A50-00-18J mounts on a sub-base and controls cylinders and actuators running on compressed air within 2 to 10 bar.
Standards and compliance
The interface of the SXE9775-A50-00-18J conforms to ISO 5599-1. For safety assessment to DIN EN ISO 13849 the manufacturer states a b10 value of 24,000,000 cycles for the SXE9775-A50-00-18J. The SXE9775-A50-00-18J is RoHS compliant, contains an SVHC substance under REACH and is covered by the WEEE directive.
Technical data
| Product type | Solenoid valve |
|---|---|
| Series | SXE |
| Product line | ISO Star |
| Standard | ISO 5599-1 |
| ISO size | ISO 3 |
| Valve function | 5/3 |
| Function | COE (centre open to exhaust) |
| Actuation | Solenoid pilot / solenoid pilot |
| Valve technology | Glandless spool and sleeve |
| Spool and sleeve | Hard anodised aluminium with special PTFE coating |
| Operating pressure | 2 to 10 bar |
| Flow | 4650 l/min |
| Medium | Compressed air |
| Temperature range | -15 to 50 °C |
| Body material | Diecast aluminium |
| Seal material | Nitrile rubber (NBR) |
| Mounting | Sub-base |
| Electrical connection | 22 mm industrial standard |
| Operating voltage | 110/120 V AC |
| Power consumption | 4/2.5 VA |
| Coil code | QM/48/18J/21 |
| Protection class | IP65 with sealed plug |
| b10 value | 24,000,000 cycles |
| Height | 62.5 mm |
| Width | 54.5 mm |
| Length | 263 mm |
| Country of origin | Germany |
| RoHS | Compliant |
| REACH | SVHC substance present |
| WEEE | WEEE |
| Weight | 0.96 kg |
| Manufacturer part number | SXE9775-A50-00-18J |
| Manufacturer | Norgren |
| Hersteller-Nr | SXE9775-A50-00-18J |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Housing material | Die-cast aluminium |
| Actuation type | Electrical |
| Norm | ISO 5599-1 |
| Certification | DIN EN ISO 13849 |
| Betriebsdruck max [bar] | 10 |
| Protection rating | IP65 |
