ISO Star solenoid valve, ISO 1, 5/2, solenoid pilot with spring return - Norgren SXE9573-A71-00-13J

Norgren SXE9573-A71-00-13J is an ISO Star valve of size ISO 1 with solenoid pilot with spring return and an operating pressure of 1.8 to 10 bar.

Benefits

• Specially coated glandless spool and sleeve for very long service life
• Low power solenoids and manual override as standard
• Bistable versions with detent mechanism
• Optional integral flow controls in ISO 1 and ISO 2
• Flow 1230 l/min at an operating pressure of 1.8 to 10 bar
• Temperature range -15 to 50 °C
• Operating voltage 24 V DC at 2 W power consumption
• b10 value 24,000,000 cycles

Applications

The valve is used in valve islands of assembly, packaging and handling systems that control compressed air at 1.8 to 10 bar.

Standards and conformity

The version is RoHS compliant, no SVHC substances are present under REACH. The product falls under the WEEE directive. The interface conforms to ISO 5599-1. For the safety assessment to DIN EN ISO 13849 the manufacturer states a b10 value of 24,000,000 cycles.
