ISO roundline double acting stainless steel cylinder, extended piston rod - Norgren KM/8025/MU/50/50
The piston position is sensed in the end positions without extra parts. The ISO roundline double acting stainless steel cylinder Norgren KM/8025/MU/50/50 has a piston diameter of 25 mm with 50 mm of stroke and covers the temperature range -5 to 80 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Pneumatic cylinders create the linear movement in fixtures, feeding and assembly equipment. The ISO roundline double acting stainless steel cylinder Norgren KM/8025/MU/50/50 develops a theoretical force of 294 N at 6 bar and works at an operating pressure of 1 to 10 bar.
Benefits
- High corrosion and acid resistance
- Magnetic piston as standard
- Conforms to ISO 6432
- Port size G1/8
- Operating pressure 1 to 10 bar
- Piston diameter 25 mm
Applications
The cylinder handles clamping, pushing and lifting on assembly machines, packaging lines and special machinery.
Standards and conformity
The version is RoHS compliant, no SVHC substances are present under REACH. The product does not fall under the WEEE directive. The product conforms to ISO 6432.
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren KM/8025/MU/50/50 |
| Series | KM/8000/M |
| Standard | ISO 6432 |
| Operating mode | Double acting |
| Port size | G1/8 |
| Piston diameter | 25 mm |
| Stroke | 50 mm |
| Theoretical force at 6 bar | 294 N |
| Operating pressure | 1 to 10 bar |
| Medium | Compressed air |
| Temperature range | -5 to 80 °C |
| Cushioning | Buffer cushioning |
| Piston version | Magnetic |
| Cylinder barrel | Stainless steel (austenitic) |
| Piston rod material | Stainless steel (austenitic) |
| Piston rod thread | Male thread |
| Piston seal | Nitrile rubber (NBR) |
| Piston rod seal | Polyurethane (PU) |
| Country of origin | Czechia |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | Non-WEEE |
| Manufacturer | Norgren |
| Hersteller-Nr | KM/8025/MU/50/50 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Norm | ISO 6432 |
