Converts compressed air into a straight movement without a gearbox. Norgren TSA/802080/M/800 develops a theoretical force of 3016 N at 80 mm piston diameter and extends by 800 mm.
ISOLine pneumatic cylinder, double acting, 80 mm bore, 800 mm stroke, G3/8 - Norgren TSA/802080/M/800
NORGREN
Original product
Net price (excl. VAT)
€626.04
Item
NRG-TSA/802080/M/800
Manufacturer no.
TSA/802080/M/800
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.TSA/802080/M/800
Customs tariff number84123100
ConditionNew
Artikel
NRG-TSA/802080/M/800
Frequently Bought Together
-
This Item:
€626.04
-
ISOLine tie-rod cylinder, double acting, 50 mm bore, 32 mm stroke, G1/4 - Norgren RA/802050/M/32/H/128
€255.52
-
Compact Cylinder - Norgren RA/192063/M/90
€200.51
Total price
Norgren TSA/802080/M/800 is a double acting pneumatic cylinder with 80 mm piston diameter, 800 mm stroke and port G3/8.
Benefits
- Piston diameter 80 mm to ISO 15552
- Stroke 800 mm
- Theoretical force 3016 N at 6 bar
- Port G3/8 on both sides
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren TSA/802080/M/800 |
| Product line | ISOLine |
| Standard | ISO 15552 |
| Operating mode | Double acting |
| Port size | G3/8 |
| Piston diameter | 80 mm |
| Stroke | 800 mm |
| Theoretical force at 6 bar | 3016 N |
| Medium | Compressed air |
Applications
The cylinder is used in fixtures, feeding technology and special machines that need 800 mm of stroke and a force of 3016 N.
Standards and conformity
The dimensions conform to ISO 15552.
| Manufacturer | Norgren |
|---|---|
| Hersteller-Nr | TSA/802080/M/800 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Norm | ISO 15552 |
