ISOLine tie-rod cylinder ISO 15552, double-acting, 63 mm bore, 254 mm stroke, G3/8 - Norgren TRA/802063/MU/254/230
The double-acting Norgren TRA/802063/MU/254/230 tie-rod cylinder to ISO 15552 travels 254 mm of stroke with a 63 mm bore and produces a theoretical 1870 N at 6 bar. It connects via G3/8 and operates from 1 to 16 bar.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
With a 63 mm bore, the Norgren TRA/802063/MU/254/230 produces a theoretical 1870 N at 6 bar over 254 mm of stroke.
Benefits
- Dimensions to ISO 15552, the TRA/802063/MU/254/230 can be exchanged for other ISO 15552 cylinders with a 63 mm bore.
- Operating pressure 1 to 16 bar with G3/8 port threads on both sides.
- Magnetic piston in the TRA/802063/MU/254/230: cylinder switches detect the end positions over 254 mm of stroke without contact.
- Temperature range of the TRA/802063/MU/254/230: -20 to 150 °C, seals made of Fluoroelastomer (FKM).
- End-position cushioning of the TRA/802063/MU/254/230 by the adaptive cushioning system ACS.
Applications
Typical installations for the TRA/802063/MU/254/230 are fixtures, feeding systems and special machines needing 254 mm of stroke and 1870 N of force at 6 bar.
Standards
Documented standards for the TRA/802063/MU/254/230: ISO 15552, VDMA 24562, NFE 49-003-1.
Technical data
| Manufacturer | Norgren |
|---|---|
| Part number | TRA/802063/MU/254/230 |
| Product line | ISOLine |
| Series | TRA/802000/M |
| Standard | ISO 15552 |
| Operating mode | double-acting |
| Bore | 63 mm |
| Stroke | 254 mm |
| Port | G3/8 |
| Theoretical force at 6 bar | 1870 N |
| Operating pressure | 1 to 16 bar |
| Medium | Compressed air |
| Temperature range | -20 to 150 °C |
| Cushioning | Adaptive cushioning system ACS |
| Magnetic piston | yes |
| Cylinder barrel | Anodised aluminium |
| Piston rod | Stainless steel (martensitic) |
| Piston rod thread | Male thread |
| Piston seal | Fluoroelastomer (FKM) |
| Piston rod seal | Fluoroelastomer (FKM) |
| Customs tariff number | 84123100 |
| Hersteller-Nr | TRA/802063/MU/254/230 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Piston Ø [mm] | 63 |
| Seal material | FKM |
| Housing material | Aluminium, anodised |
| Function | double-acting |
| Norm | ISO 15552, VDMA 24562 |
| Betriebsdruck max [bar] | 16 |
| Pneumatic connection | G3/8 |
| Temperaturbereich | -20-150 °C |
| Temperature (max.) | 150 |
