Converts compressed air into a straight movement without a gearbox. Norgren PRA/802100/M/795 develops a theoretical force of 4710 N at 100 mm piston diameter and extends by 795 mm.
ISOLine profile cylinder, double acting, 100 mm bore, 795 mm stroke, G1/2 - Norgren PRA/802100/M/795
NORGREN
Original product
Net price (excl. VAT)
€440.79
Item
NRG-PRA/802100/M/795
Manufacturer no.
PRA/802100/M/795
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.PRA/802100/M/795
Customs tariff number84123100
ConditionNew
Artikel
NRG-PRA/802100/M/795
Frequently Bought Together
-
This Item:
€440.79
-
ISOLine tie-rod cylinder, double acting, 100 mm bore, 1000 mm stroke, G1/2 - Norgren HRA/802100/M/1000
€639.35
-
Compact Cylinder - Norgren RA/192080/L4/300
€1,536.30
Total price
With 100 mm piston diameter and 795 mm stroke the profile cylinder Norgren PRA/802100/M/795 delivers a theoretical force of 4710 N at 6 bar.
Benefits
- Magnetic piston for contactless end position sensing
- Piston diameter 100 mm to ISO 15552
- Stroke 795 mm
- Theoretical force 4710 N at 6 bar
- Port G1/2 on both sides
- Operating pressure 1 to 12 bar
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren PRA/802100/M/795 |
| Series | PRA/802000/M |
| Product line | ISOLine |
| Standard | ISO 15552 |
| Operating mode | Double acting |
| Port size | G1/2 |
| Piston diameter | 100 mm |
| Stroke | 795 mm |
| Theoretical force at 6 bar | 4710 N |
| Operating pressure | 1 to 12 bar |
| Medium | Compressed air |
| Temperature range | -20 to 80 °C |
| Cushioning | Adaptive cushioning system ACS |
| Piston version | Magnetic |
| Cylinder barrel | Anodised aluminium |
| Piston rod material | Stainless steel (martensitic) |
| Piston seal | Polyurethane (PU) |
| Piston rod seal | Polyurethane (PU) |
Applications
Typical installations are assembly machines, packaging lines and handling units with an operating pressure of 1 to 12 bar.
Standards and conformity
The dimensions conform to ISO 15552. VDMA 24562 and NFE 49-003-1 therefore apply as well. The piston seal is made of Polyurethane (PU). The permissible temperature range is -20 to 80 °C.
| Manufacturer | Norgren |
|---|---|
| Hersteller-Nr | PRA/802100/M/795 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Norm | ISO 15552, VDMA 24562 |
