ISOLine ISO 15552 tie-rod cylinder, double-acting, 100 mm bore, 125 mm stroke, G1/2, magnetic piston - Norgren DA/802100/M/125/F/H/S/190
Double-acting tie-rod cylinder with 100 mm bore and 125 mm stroke that delivers a theoretical 4710 N at 6 bar. Mounting dimensions to ISO 15552 and a G1/2 port make it interchangeable with cylinders of the same size and 100 mm bore.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
A theoretical 4710 N at 6 bar and 125 mm of stroke: the Norgren DA/802100/M/125/F/H/S/190 with 100 mm bore is a double-acting tie-rod cylinder from the ISOLine range.
Benefits
- Mounting dimensions to ISO 15552, so it can replace cylinders of this standard with 100 mm bore.
- Cylinder switches pick up any position via the magnetic piston on 125 mm of stroke with a 100 mm bore.
- Permitted pressure is 1 to 16 bar with 100 mm bore and 125 mm stroke.
- On the DA/802100/M/125/F/H/S/190, the Adaptive Cushioning System (ACS) handles end-position cushioning.
- Materials on the 100 mm bore version: barrel in anodised aluminium, piston rod in hard chrome-plated steel with male thread, seals in polyurethane (PU).
- Rated for -20 to 80 °C with 100 mm bore and 125 mm stroke.
Applications
The cylinder is used for clamping, pushing and lifting in fixtures and special machines, sized for 100 mm bore and 125 mm stroke.
Technical data
| Product line | ISOLine |
|---|---|
| Series | DA/802000/M |
| Standard | ISO 15552 |
| Operating mode | double-acting |
| Bore | 100 mm |
| Stroke | 125 mm |
| Port | G1/2 |
| Theoretical force at 6 bar | 4710 N |
| Operating pressure | 1 to 16 bar |
| Medium | compressed air |
| Temperature range | -20 to 80 °C |
| Cushioning | Adaptive Cushioning System (ACS) |
| Magnetic piston | yes |
| Barrel | anodised aluminium |
| Piston rod | hard chrome-plated steel |
| Piston rod thread | male thread |
| Piston seal | polyurethane (PU) |
| Piston rod seal | polyurethane (PU) |
| Manufacturer | Norgren |
| Hersteller-Nr | DA/802100/M/125/F/H/S/190 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Piston Ø [mm] | 100 |
| Stroke [mm] | 125 |
| Seal material | PU |
| Housing material | Aluminium, anodised |
| Function | double-acting |
| Norm | ISO 15552 |
| Betriebsdruck max [bar] | 16 |
| Pneumatic connection | G1/2 |
| Temperaturbereich | -20-80 °C |
| Temperature (max.) | 80 |
