ISO compact cylinder, double acting, 100 mm bore, 20 mm stroke, female piston rod thread - Norgren RA/192100/N2X/20

With a barrel of anodised aluminium and a piston rod of martensitic stainless steel Norgren RA/192100/N2X/20 covers 100 mm piston diameter at 20 mm stroke.

Benefits

• Conforms to ISO 21287
• Magnetic piston as standard
• Low friction seals with long service life
• Theoretical force 4710 N at 100 mm piston diameter
• Stroke 20 mm at an operating pressure of 1 to 10 bar
• Barrel made of anodised aluminium, piston rod made of martensitic stainless steel

Applications

Typical installations are feeding units, test benches and welding fixtures with temperatures of -5 to 80 °C.

Standards and conformity

The version is not RoHS compliant, an SVHC substance is present under REACH. The product does not fall under the WEEE directive. The cylinder conforms to ISO 21287. The piston seal is made of Nitrile rubber (NBR).
