Solenoid actuated flange valve, 50 mm nominal diameter, 2/2 NC, 24 V DC, cast steel - Norgren 8303714.9152.02400

Norgren 8303714.9152.02400 is a solenoid actuated flange valve in function 2/2 NC and switches gases and liquids at an operating pressure of 0.1 to 16 bar.

Benefits

• High flow rate with damped operation
• Operating pressure 0.1 to 16 bar in function 2/2 NC
• Kv value 41 m³/h and Cv value 47.4 gpm
• Seal material Ethylene propylene diene monomer (EPDM) for fluid temperatures of -10 to 90 °C
• Protection class IP65 at an ambient temperature of -10 to 50 °C

Applications

Typical installations are cooling circuits, washing and filling plants and gas lines with fluid temperatures of -10 to 90 °C.

Standards and conformity

The version is RoHS compliant, no SVHC substances are present under REACH. The product falls under the WEEE directive. The electrical connection follows DIN EN 175301-803 form A. The housing reaches protection class IP65.
